Home > Products > Grating platform > steel Sidewalk Gratings 20years professional manufacturer
steel Sidewalk Gratings 20years professional manufacturer
- 2147483647 Square Meter / Square Meters per Month
- tianjin port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Tianjin, China | Brand Name: | JIUWANG | Model Number: | 19-W-4; 15-W-2,12.5/25/30/32.5/35/40/50mm.etc |
Material: | Steel |
Product Description
Specifications
1steel Sidewalk Gratings2. tenstile &corrosion
3.beautiful surface
4.hot dipped galvanized
5.ISO9001
1.what is off shore oil platform steel grating ?( steel Sidewalk Gratings) -- steel grating ( platform grating ) is made by bearing bar and cross bar according to the flat-steel weft arrangement, in high-pressure spacing on resistance welder welded by cutting, incision, opening, overlock process such as processing and into customer requirements finished products
Bearing bar pitch | Cross bar pitch | load steel size ( Width ×Thickness) | |||||
20×3 | 25×3 | 32×3 | 40×3 | 20×5 | 25×5 | ||
30 | 100 | G203/30/100 | G253/30/100 | G323/30/100 | G403/30/100 | G205/30/100 | G255/30/100 |
50 | G203/30/50 | G253/30/50 | G323/30/50 | G403/30/50 | G205/30/50 | G255/30/50 | |
40 | 100 | G203/40/100 | G253/40/100 | G323/40/100 | G403/40/100 | G205/40/100 | G255/40/100 |
50 | G203/40/50 | G253/40/50 | G323/40/50 | G403/40/50 | G205/40/50 | G255/40/50 | |
60 | 50 | - | G253/60/50 | G253/60/50 | G403/60/50 | G205/60/50 | G255/60/50 |
Bearing bar pitch | Cross bar pitch | load steel size (Width ×Thickness) | |||||
32×5 | 40×5 | 45×5 | 50×5 | 55×5 | 60×5 | ||
30 | 100 | G325/30/100 | G405/30/100 | G455/30/100 | G505/30/100 | G555/30/100 | G605/30/100 |
50 | G325/30/50 | G405/30/50 | G455/30/50 | G505/30/50 | G555/30/50 | G605/30/50 | |
40 | 100 | G325/40/100 | G405/40/100 | G455/40/100 | G505/40/100 | G555/40/100 | G605/40/100 |
50 | G325/40/50 | G405/40/50 | G455/40/50 | G505/40/50 | G555/40/50 | G605/40/50 | |
60 | 50 | G325/60/50 | G405/60/50 | G455/60/50 | G505/60/50 | G555/60/50 | G605/60/50 |
3.international standard - steel Sidewalk Gratings
Steel Grating Standard | |||
| Steel Grating Standard | Steel Standard | Galvanizing Standard |
China Standard | YB/T 4001.1-2007 | GB700-88 | GB/T13912-2002 |
USA Standard | ANSI/NAAMM (MBG531) | ASTM (A36) | ASTM (A123) |
U.K. Standard | BS4592 | BS4360 (43A) | BS729 |
Australia Standard | AS1657 | AS3679 | AS1650 |
Deutsche Standard | DIN24537 | DIN17100-80 | DIN50976 |
4. steel Sidewalk Gratings common introduction-
Features: | Durable, heat-resistant wear-resisting, fight stress is strong. |
Usage:
| Widely used in coal, mining, petroleum, chemical industry in the screening and filtration, dehydration, desliming etc . It has very high strength and carrying capacity, Our company can make various shapes of screening filtering device according to customer request.
|
Material: | Carbon steel, Stainless steel and so on |
Surface treatment:
| Hot-dipped-galvanized ,electro galvanized or PVC coated ....
|
Size: | Standard or OEM(Making as the customers request). |
Packing: | Naked or packing as the customers reques
|
5.delivery terms- hot dip galvanized steel Sidewalk Gratings
Delivery | Within 15-20 days after receiving the deposit |
Payment terms | EXW: 100% T/T. FOB: T/T, 30% deposit, 70% balance payment before shipping. CIF: T/T, 30% deposit, 70% balance payment at the sight of copy of B/L. |
HS code | 7308900000 |
Price validity | Within 7 days |
6 hot dip galvanized steel Sidewalk Gratings manufacturing process
steel grating platfform
trench cover grating
steel grating ceiling
steel stair treads
