Plasma Cutter Plasma Cutting Machine

Plasma Cutter Plasma Cutting Machine thumbnail-1
Plasma Cutter Plasma Cutting Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
KIND
Contact Supplier Request Quote Chat Now
Foshan City Fuyin Welding Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Guangdong, China
Brand Name KIND
Model Number LGK-100
Voltage 380V, 50/60Hz, 3 phase
Rated Power 15.2KVA
Dimension(L*W*H) 650*330*620mm
Weight 40kg
Certification CCC, CE, CQC
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Plasma cutter plasma cutting machine





Product Description

Model

KIND-540

LGK-100

KIND-540

LGK-120

KIND-540

LGK-160

Input
Voltage

380V
50/60Hz,3 phase

380V
50/60Hz,3 phase

380V
50/60Hz,3 phase

Rated
Power

15.2KVA

19.4KVA

30KVA

Output

Current
Adjustment

30-100A

30-120A

30-160A

Output

Voltage

120V

128V

144V

Arc

Starting

Non-contact

Non-contact

Non-contact

Duty
Cycle

60%

60%

60%

No-load

Voltage

350V

350V

350V

Max Cutting

Thickness

35MM

45MM

50MM

Air Compressor Capacity

0.36m2/MIN

0.36m2/MIN

0.36m2/MIN

Protection
Class

IP21S

IP21S

IP21S

Insulation
Class

F

F

F

Cooling Type

Air-cooling

Air-cooling

Air-cooling

N.W

40KG

45KG

48.3KG

Dimensions

650*330*620mm

650*330*620mm

650*330*620mm



Plasma cutter plasma cutting machine

1, Performance Characteristics

1), Adopt MCU control technology;

2), Stability output current, workpiece is not easy to deformation;

3), Non-contact high frequency arc starting and higher success rate;

4), There is the function of locking and non-locking, reduce labor intensity;

5), Cutting openings is smooth and higher cutting precision;

6), Can match CNC machine use (optional functions).

2, Materials Welding: Carbon Steel, Stainless steel, Non-ferrous metal etc

3, Usage: Heavy Industry etc

4, Application: Machinery manufacturing, vehicle manufacturing, shipbuilding  manufacturing, chemical vessel etc.

5, R&D Team and Quality Control

Our R&D center has a young and experienced R&D team. They are the industry's elite and the pioneer, the R&D department is responsible for new technology, new product research and development and industrial production follow-up.

Our company makes use of advanced production equipment and testing equipment following the ISO9001 quality assurance system, which is in strict accordance with the requirements of production to ensure product quality and reliability. The production process to implement the "three inspection" (self-inspection, mutual inspection, special inspection) procedures to ensure control of product quality. The manufactured products require the "three pass" (raw material into the plant pass, semi-finished product pass, finished off the factory pass) to ensure reaching the required quality; finished product storage, transportation and sales in the market were also included in the product quality management.

6, Our Services





Our Services

1), We will be answer within 24 hours, welcome to contact with us if you have any problems. we warmly welcome to visit our company and looking forward to cooperating with you.

2), We can offer OEM or ODM service, according to customers requirements.

3), Unique and exclusive solution can be provided to our customers by our professional engineers.

7, Packaging & Shipping





Packaging & Shipping
1), Standard export packaging, or they are packing to meet your requirement.
2), Payment type: T/T(Confirm contract pay 30% deposit, pay the balance before delivery).
3), Delivery time is 10-15 working days after receiving deposit.
4), Warranty: One year warranty, the Seller shall supply the free replacement spare parts (but NOT including the mould, wearing parts and the items of wrong using), and the delivery cost will bear on the buyer’s account.

8, Sales Markets

Foshan Fuyin Welding Equipment Co., Ltd is a professional manufacturing and developing company in the line of spot welding machine and Automatic devices of wire products series products. Our products are exported to South America, Mid East, Russia, Europe and countries around the world.

Plasma cutter plasma cutting machine

For more information, please feel free to contact us, your satisfaction is our top priority!



Contact: Cunlu Liu

Cel: +86 1392 7707 025

Tel: +86 757 633 69302

Fax: +86 757 885 72629

Skype: fsfuyin.welding
