YAG Laser Marking Machine for Bearings with Rotation Device are detailed as follow:
Machine Advantages:
1. The size of YAG Laser Marking Machine is small. The volume is only 1/4 of the traditional lamp pump laser.
2. The optical system uses the fully sealed structure to prevent the dust enters laser body and reduces the equipment failure rate.
3. The machine is able to preview the light path and point out the focus, which are very convenient for the materials that will be processed to be located.
4. This machine provides the precise three dimension worktable and newest outside water- cooling system. The cooling system can control the water temperature very accurately, which ensures the long time working. Anyway, the machine movement noise is extremely low.
5. The software own intellectual property rights. It is compatible with file formats saved by
CORELDRAW, AUTOCAD, PHOTOSHOP and other software. It can mark autocode, sequence number, batch number, date, bar code, two-dimension code, etc. Anyway, the software can mark reversely.
Machine Parameters
Type |
laser marking machine |
Laser Power |
50W/75W |
Laser Wavelength |
1064nm |
Cooling System |
Water cooling |
Beam Quality |
M2<6 |
Laser Repetition Frequency |
less than 50KHz |
Marking Area |
200mm*200mm |
Marking Depth |
less than 0.3mm |
Linear Speed |
7000mm/s |
Min. Line Width |
0.02mm |
Min. Letter |
0.25mm |
Repeatable Accuracy |
±0.001mm |
Gross Power |
less than 2.5KW |
Electricity Source |
220V/50Hz/15A |
Applicable Materials:
This laser marking machine is widely applied in most metal marking industry such as brass, titanium, steel, iron, aluminium and so on.
It can mark on many non-metals also. For example, ABS, nylon, PES, PVC, makrolon, etc.
Applicable Industries:
Electronics industry, communication, electrical equipment, clock and watch, glass, jewelry, dress and personal adornment, instrument, label, tag, car industry, ship-building,Space flight and aviation,etc.
Parts of machine picture:
Rotary :
Worktable :
Module:
Fliter:
Sample Picture:
P1:
P2:
