Co2 Laser Cutting Engraving Machines

Co2 Laser Cutting Engraving Machines thumbnail-1
Co2 Laser Cutting Engraving Machines photo-1
US$ 4,000 - 6,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Engraving Area:
900*1200mm laser engraving machine eastern
Contact Supplier Request Quote Chat Now
Jinan Xintian Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Laser Type CO2
Engraving Area 900*1200mm laser engraving machine eastern
Engraving Speed 0-70000mm/s laser engraving machine eastern
CNC or Not Yes
Cooling Mode Water Cooling
Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
Graphic Format Supported PLT
Place of Origin Shandong, China
Brand Name xintian co2 laser engraving machines
Model Number XTE-1290co2 laser engraving machines
Dimension(L*W*H) 1450mm*1060mm*1350mm
Certification CE, ISO
After-sales Service Provided Engineers available to service machinery overseas

Welcome to contact XT laser by leaving a message below or send inquiry to xintian101(at) for further information.Your kind response of below questions will help us to recomemnd the most suitable model to you asap.
1,Are you looking for laser cutting machine or laser engraving machine?
2,Which material need to cut or engrave ?
3,What is the thickness and size of materials?









Product Description





co2 laser engraving machines  Feature



  • All working travel area has fixed width but infinite length material feeding.
  • various power choices of laser tube for you to choose
  • being able to engrave and cut most non-metal materials
  • well-structured, customized design
  • machine is able to work without connecting to a computer
  • Leetro USB offline control system; front operate panel with LCD screen
  • optional platform: honeycomb platform, up/down lifting platform
  • water cooling system (water pump / water chiller), cools and protects the laser tube
  • air pump, protects the material being engraved/cut from fire and helps to get better effect
  • passed CE certificate
  co2 laser engraving machines Application

Processing industries of large-acale engraving and cutting, clipping industry, building upholster industry, acrylic product industry, advertisement decoration industry, advertisement signs and marks making industry, crystal accessories industry, art gift industry, handicraft industry, package and printing industry, paper product industry, construction model industry, wooden and bamboo product industry, umbrella industry, cloth toys industry, computer embroidery industry, textiles industry, garment industry, clothing, shoes and leather industry, template cutting industry, plate making industry, middle density board, non-metal sheet precision cutting and other industries.

Materials Can Be Engraved

acrylic, plexiglass, wood, bamboo, MDF, leather, rubber, glass, crystal, granite, marble, tile, ceramic, painted metal, metal coating, double-color sheet,etc.

Materials Can Be Cut

acrylic, plexiglass, wood, cloth, fabric, leather, MDF, plywood, rubber, asbestos rubber, paper, PVC, foam, EVA, plastic, double-color sheet, etc


  co2 laser engraving machines machine detailed information





  co2 laser engraving machines Technical specifications



Models Available XTE-6040 / XTE-9060 / XTE-1290 / XTE-1490 / XTE-1325
Laser Wavelength 10.64μm
Laser Type Sealed CO2 Laser Tube
Laser Power * for Available, - for Unavailable
40W * / * / * / * / -
60W * / * / * / * / *
80W * / * / * / * / *
100W - / * / * / * / *
130W - / - / * / * / *
150W - / - / * / * / *
180W - / - / * / * / *
Control System Leetro off-line control system
Control of Laser Power 0-100% Controlled by software
Machine Control and Drive Speedy DSP controlling, stepper motor
Max Engraving Speed 60000mm/min
Max Cutting Speed 30000mm/min
Repeating Location 0.01mm
Minimum Character Chinese characters: 1.5mm; English words: 1mm
Working Travel Area(W*L unit:mm) 600*400 / 900*600 / 1200*900 / 1400*900 / 1300*2500
Cooling System Circulating-water-cooling(water pump)
Working Voltage 220V/50Hz
Working Environment Temperature:0-45°C, Humidity:5%-95%
Controlling Software Language Chinese,English
Dictate Format *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support AutoCAD, CoreDraw direct outputting







    co2 laser engraving machines standard accessories and optional parts



co2 laser cutting engraving machines



  co2 laser engraving machines   sample Photos



co2 laser cutting engraving machines





Packaging & Shipping



  co2 laser engraving machines  packaging photo

 co2 laser cutting engraving machines



    co2 laser engraving machines after service



co2 laser cutting engraving machines



24/7 service is available to each customer. And if any technical questions or problems, our engineers will help you and give you solutions on the phone or by face-to-face communication online.
One-year warranty is provided. (The detailed reference will be written into the final contract.)
Professional staff for installation and training if needed.
Spare parts are supplying on time or doing some inventory if promising certain sales volume.
Faster delivery, we will support our sole agent to do the stock if good sales, then more convenient and helpful.
If the sales are good, we will arrange some famous exhibition fairs in the local or surroundings, and give our full support to our agents at the fair. We will provide our sample machines, catalog, DVD, manuals, etc. All native customers belong to our local agent, which is our basic rule. And we promise the final delivery is the same as displayed prototype.





Company Information



 company information



Jinan XinTian Technology Co., Ltd was established in 2004. It is a professional manufacturer engaged in the research, development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine, CO2 laser marking machine, Pneumatic marking machine, Laser engraving machine, Laser welding machine, Laser cutting machine and Laser trimming machine.



certificate






We have a variety of product models for your check:



  • fiber laser marking machine
  • Semiconductor side-pumped laser marking machine
  • CO2 RF laser marking machine
  • pneumatic marking machine







FAQ



 contact inofrmation



 co2 laser cutting engraving machines

we are also finding overseas distributor of our Co2 laser engraving machine , fiber laser marking machine  ,Mini fiber laser marking machine,diode laser marking machine,dot peen marking machine etc .
