Specifications
1:cosmetics diode laser marking machine;2:Import laser head available;
3:Germany Galvo head;
4:English software and Video.
Cosmetics diode laser marking machine
| Features |
1. imported UK ceramic condenser chamber, resistant to elevated temperature and corrosion, long life (8-10 years), high photoelectric conversion rate, no need to adjust the lifting plate form to focus when doing engraving within 3mm depth, The speed of making one-time 1mm engraving is 3 times than our Opponent;
2. Large power,controled by eletric and software,tunable;
3. Low cost,without ink and other print consumables;
4. Scanned with high precision by galvo head;
5. 24 hrs continuously working;
6. Depth: aluminium plate 5mm, steel plate 3mm;
7 .Speed:5mm x 5mm steel plate:0.6mm in 10 minutes
| Application |
A):all kinds of ordinary metals and alloys(Iron, copper, aluminium, magnesium, zinc and all metals);
B):rare metals and alloys (gold, silver, titanium); metal oxides,
ABS material (electrical appliancescase, daily necessities);
C): ink (translucent key-press, printing products);
D)epoxy resin(electronic components packaging, insulation layer).
| Technical Specifications |
Max.Outout Power |
75W |
Repetition Precision |
±0.03mm |
Laser Wavelength |
1064nm |
Machine power |
2KW |
Repetition Frequency |
≤50KHZ |
Electric Power Demand |
220V/Single Phase/50Hz/8A |
Standard Marking Scope |
100mmX100mm(optical) |
Optical-Path System Size |
1200mm*190mm*200mm |
Marking Depth |
≤1mm |
Controlling Size |
600mm*600mm*800mm |
Marking speed |
≤7000mm/s |
Min.Character |
0.3mm |
Min.Line Width |
0.015mm |
|
|
| Sample Photo |
| Machine Photo |
| Package Photo |
| After-sale Service |
| 24/7 service is available to each customer. And if any technical questions or problems, our engineers will help you and give you solutions on the phone or by face-to-face communication online. |
| One-year warranty is provided. (The detailed reference will be written into the final contract.) |
| Professional staff for installation and training if needed. |
| Spare parts are supplying on time or doing some inventory if promising certain sales volume. |
| Faster delivery, we will support our sole agent to do the stock if good sales, then more convenient and helpful. |
| If the sales are good, we will arrange some famous exhibition fairs in the local or surroundings, and give our full support to our agents at the fair. We will provide our sample machines, catalog, DVD, manuals, etc. All native customers belong to our local agent, which is our basic rule. And we promise the final delivery is the same as displayed prototype. |
| Company, Exhibition, Certification |
| The Series Of Products |
- fiber laser marking machine
- Semiconductor side-pumped laser marking machine
- CO2 RF laser marking machine
- pneumatic marking machine
