Specifications
1)Trustworthy mini/small size laser cutting and engraving machine2)40/60/80W laser tube
3)water cooling system
mini laser cutting and engraving machine----XTL-3636
Specifications:
mini laser cutting and engraving machine
1,USB interface
2,fast speed and high precision
3.LCD operate panel
4support coreldraw,AutoCAD
Model |
XTL-3636 |
Working area : |
360cm*360cm / 47in*35in (L*W) |
Laser power : |
100W |
Laser type : |
CO2 sealed laser tube,water-cooled |
Engraving speed : |
25-24000mm/min |
Cutting speed : |
50-5000mm/min |
Power supply : |
220V±10% /50HZ , 110V±10%//60HZ |
Min. shaping character : |
Letter 1.0 x 1.0mm |
Graphic format supported: |
BMP, PLT, DST, DXF, AI,CDR |
Software supported : |
CorelDraw, PhotoShop, AutoCAD |
Laser Output Control: |
1-100% software setting |
Highest Scanning Precision: |
2000DPI |
Resolution ratio : |
<0.01mm |
Location precision: |
<0.01mm |
Working temperature: |
540 |
Operating humidity: |
5%-95%(without condensed water) |
Equipment Dimension: |
1650mm*1250mm*970mm/65in*49in*38 in (L*W*H)
|
Net Weight |
350KG |
Optional parts : |
Up-down worktable, Red light pointer, Auto focus, Rotary device |
Accessories: Nessary Attachment like: water cooling ,exhaust fans , air compressor. Software, English friendly user manual , data cable and other free parts
Samples:
Certifications:
Exhibitions:
About us:
Jinan XinTian Technology Co., Ltd was established in 2004, It is a professional manufacturer engaged in research,development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine,CO2 laser marking machine,Pneumatic marking machine,Laser engraving machine,Laser welding machine, Laser cutting machine and Laser trimming machine.
Wooden Package:
Other products:
Name cards:
Please advise us the following information, so that we can recommend you the most suitable model quickly, feel free to contact us soon !
(1) Which Material will be processed? stainless steel,metal,wood,acrylic,fabric,leather,textile etc.?
(2) What is the size and thickness of the material?
(3)What is your business scope? Are you a distributor or end-user ?
