Specifications
1)Laser hollow carving machine2)40/60/80W laser tube
3)water cooling
4)Leetro controller
Laser hollow carving machine
Machine Description
1) 40w/60w/80w laser tube for your choice. Able to engrave and cut most non-metal materials.
2) Water cooling system (water pump / water chiller), cools and protects the laser tube.
3) Air pump, protects the material being engraved/cut from fire and helps to get better effect.
4) Exhaust fan and pipes, remove dust and smoke to protect optical parts and the user.
5) Aluminum blade table, holds hard sheet materials. Optional tables: honeycomb table, up/down lifting table.
6) Leetro USB controller system. Machine is able to work without connecting to a computer.
7)Imported lens and mirrors, brings high engraving and cutting precision.
8) Linear rails from Taiwan, more stable and precise.
9) English Lasercut 5.3 software.
10) Options: red dot, up/down lifting table, honeycomb table, rotary, etc.
Materials can be engraved:
acrylic, wood, cloth, leather, MDF, bamboo, rubber, glass, crystal, granite, marble, tile, ceramic, paper, magic bean, painted metal, etc.
Materials can be cut:
acrylic, wood, cloth, leather, MDF, plywood, bamboo, rubber, asbestos rubber, paper, PVC, foam, EVA, plastic, etc.
Technical Parameters
Model |
XTL-9060 |
|
|
|
|
|
|
Laser type |
Hermetic and detached CO2 laser tube |
||||||
Laser power |
60W/80W/100W/140W |
||||||
cutting speed |
25-40000mm/min |
||||||
Resetting positioning accuracy |
0.01mm |
||||||
Resolution radio |
0.025mm |
||||||
Highest Scanning Precision |
2500DPI |
||||||
Graphic format |
Al, Plt, Cdr, Dxf, Dst, Nc, BMP, JPG, DST, PLT, DXF |
||||||
Supporting software |
TAJIMA, CorelDraw, Photoshop, AutoCAD |
||||||
Identify colors cutting |
Up to 256 layers |
||||||
Power supply |
220V/50HZ |
||||||
Whole power |
<1250W |
||||||
Machine Details
Sample Picture:
Certifications:
Exhibitions:
About us:
Jinan XinTian Technology Co., Ltd was established in 2004, It is a professional manufacturer engaged in research,development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine,CO2 laser marking machine,Pneumatic marking machine,Laser engraving machine,Laser welding machine, Laser cutting machine and Laser trimming machine.
Other products:
Name cards:
