Fiber Laser Cutting Machine for Medical Technology / Kitchen Utensils / Hardware

Name: Fiber Laser Cutting Machine for Medical Technology / Kitchen Utensils / Hardware
Brand: XT Laser Cutting Machine
SKU: 133987615
Availability: InStock

Fiber Laser Cutting Machine for Medical Technology / Kitchen Utensils / Hardware thumbnail-1

Fiber Laser Cutting Machine for Medical Technology / Kitchen Utensils / Hardware photo-1

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Laser Type:

Fiber Laser

Engraving Area:

3*1.5m

Contact Supplier Request Quote Chat Now

Jinan Xintian Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Laser Type Fiber Laser

Engraving Area 3*1.5m

Engraving Speed 1-30m/min

CNC or Not Yes

Cooling Mode Water Cooling

Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Graphic Format Supported AI, BMP, DST, DWG, DXF, DXP, LAS, PLT

Place of Origin Shandong, China

Brand Name XT Laser Cutting Machine

Model Number XTC-F500

Dimension(L*W*H) 1.5m*3m*1.2m

Certification CCC, CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

Product Description

WHAT IS FIBER LASER CUTTING?
A fiber laser is a laser in which the active gain medium is an optical fiber doped with rare-earth elements such as erbium. The way it generates its beam is distinctly different from that of a Co2 laser which uses resonators. Fiber lasers are much more ecofriendly than Co2 lasers using typically less than 50% power consumption compared to a Co2 Laser. They are also more reliable and cut parts up to 6mm thick 30-40% quicker than a Co2 Laser.

THE ADVANTAGES OF FIBER LASER CUTTING:
Additional power and better beam quality provide cleaner cut edges and faster cutting speeds, typically 30-40% faster on thicknesses up to and including 6mm
Ability to cut aluminium, copper and brass where a Co2 laser can’t
Reliability: fiber lasers exhibit high vibrational stability, extended lifetime, and maintenance-free turnkey operation
High quality edge finish
High peak power and nanosecond pulses enable effective marking and engraving
Intricate parts can be manufactured easily, quicker and far more cost effectively than machining or even Co2 lasers depending on thickness

1530 fiber laser cutting machine for stainless steel and mild steel

Features and Advantages of 1530 Fiber Laser Cutting Machine For Stainless Steel And Mild Steel 1530:

Compact structure, small floor area.
Stability and reliability of light path system and control system.
High performance and low operating cost, famous IPG fiber laser with up to more than 100 thousand hours life-cycle.
Higher cutting quality and efficiency, cutting speed is up to 15 m/min with appearance and beautiful cutting edge.
High precision serve motors, lead screws and guide ways with famous brands to ensure the efficiency and accuracy, greatly increasing the stability and reliability.
Fiber Laser Cutting Machine XTC-F500 has faster cutting speed and higher quality cuting result compared to other cutting solutions. Fiber Metal Laser Cutting Equipment XTC-F500 Series adopts the most sophisticated America IPG laser, combining CNC Machinery designed by our company and high strength welding body, after standard heat treatment and process machining by large CNC milling machine

Fiber Laser Cutting Machines Series Model:

XTC-F500 Fiber Laser Cutting Machine 3000X1500mm
XTC-H150/180/200 Fiber Laser Cutting Machine 2500X1300mm
XTC-Y600 Fiber Laser Cutting Machine 3000x1500/2500*1300/1200*1200mm
(Remark: Specific model should be produced with signed contract)

Technical Parameters of 1530 Fiber Laser Cutting Machine For Stainless Steel And Mild Steel 1530:

Model	XTC-F500	XTC-F300	XTC-F1000
Working Area	3000X1500mm	3000X1500mm	4000x2000mm
Laser Type	Raycus Fiber laser generator
Laser Power	500W
Cutting Thickness	0-10mm
Cutting Speed	0-30m/min
Laser Wavelength	1064 nm
Positioning Accuracy	≤ ±0.03mm/m
Re-positioning Accuracy	≤±0.02mm/m
Max Cutting Speed	30m/min(depending on material and thickness)
Power Supply Rated Voltage	3-phase 380V/50Hz
X-axis Stroke	3000mm	3000mm	4000mm
Y-axis Stroke	1500mm	1500mm	2000mm
Z-axis Stroke	120mm
Working Table	Rack working platform
Control System	Baichu Cypcut CNC control system
Location System	Red dot indicator
Water Cooling System	Constant temperature water chiller
Machine Weight	2000-8000kg
Machine Dimension	3500x1800x1600mm	4300x2500x1600mm	5000X2900X1600mm
Remark	Automatic exchange worktable, cover(option)

XTC-F500 Fiber Laser Cutting Machine

Standard Accessories of 1530 Fiber Laser Cutting Machine For Stainless Steel And Mild Steel 1530

Applications of 1530 Fiber Laser Cutting Machine For Stainless Steel And Mild Steel 1530:

Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc.

Application Industries: Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.

Packaging & Shipping

Our Services

After-sale Service:

1. 24/7 service is available to each customer. And if any technical questions or problems, our engineers will help you and give you solutions on the phone or by face-to-face communication online.
2. One-year warranty is provided. (The detailed reference will be written into the final contract.)
3. Professional staff for installation and training if needed.
4. Spare parts are supplying on time or doing some inventory if promising certain sales volume.
5. Faster delivery, we will support our sole agent to do the stock if good sales, then more convenient and helpful.
6. If the sales are good, we will arrange some famous exhibition fairs in the local or surroundings, and give our full support to our agents at the fair. We will provide our sample machines, catalog, DVD, manuals, etc. All native customers belong to our local agent, which is our basic rule. And we promise the final delivery is the same as displayed prototype.

About Us:

Jinan XinTian Technology Co., Ltd was established in 2004. It is a professional manufacturer engaged in the research, development, production and service of Diode pumped Laser marking machine, Fiber laser marking machine, CO2 laser marking machine, Pneumatic marking machine, Laser engraving machine, Laser welding machine, Laser cutting machine and Laser trimming machine.
