Specifications
Steel Plate Edge Milling Machine1.Quickly bevelling
2.Low labor intensity
3.High efficiency
4.Small volume, Light weight
Steel Plate Edge Milling Machine :
The machine can processing plate thickness 4 to 15mm, N.W is 28.5kg, bevelling speed 1.2m/min.
Features:
1.Quickly bevelling;
2.Low labor intensity;
3.High efficiency;
4.Small volume, Light weight;
5.Low noise for bevel processing;
6.Cold bevelling without oxidation;
7.Efficency & freee maintenance gearbox.
Advantage:
Net weight is only 29kgs
High efficiency of reduction gear box
High power motor:400W
Max.bevel width:8mm
Cold cutting, non-oxidation on the surface
High efficiency:1.8m/min
No scrap iron splash, more safe
Can process steel, pipeline, pipe head
Power Supply: AC 380V/220V 50Hz
Motor Power:400W
Motor Speed:1400RPM
Bevel Speed:1.2-1.8m/min
Bevel Angle:25 Deg, 30 Deg, 35 Deg, 40 Deg, 45 Deg.
Single Bevel Width:6mm
Max. Bevel Width:8mm
Processing Plate Thickness:4-16mm
Processing Pipe-line Dia: > Dia 260mm
Processing Tube Dia: > Dia 110mm
Min.Processing Plate Width: >55mm
Net Weight:29kgs
Net weight(include vehicle ):35kgs
Processing case:
Package:
