Help CenterSeries DZSF Heavy-duty Motor Vibrating Screen
Related Products
Specifications
1.Small size, light in weight, easy to install and layout.2. High screening capacity and low energy consumption.
Introduction:
Series DZSF heavy-duty motor vibrating screen is a universal screening equipment, which is widely used in mining, coal, electricity, refractories, metallurgy, building materials and other industries. It is usually used for the screening and grading operations of materials in large, middle and small particles.
Series DZSF heavy-duty motor vibrating screen is made up of the excitation device, screen boxes, drop-hopper, vibration damping device and the base. The excitation device uses energy-saving vibration motor as the vibration source, and the vibration damping device is supported by the spring.
The screening surface of series DZSF motor vibrating screen is inclined installed, and the inclination angle is 10°-20°.
Features:
1. Small size, light in weight, easy to install and layout.
2. High screening capacity and low energy consumption.
3. Simple structure, good appearance and less spare parts.
4. The screening mesh is made up of wearable bar strips, durable and easy to replace.
5. Materials are blanking layer by layer and can not be blocked easily.
6. Good flexibility and operational reliability.
Technical parameters:
| Model No. | Feeding size (mm) |
Capacity (t/h) |
Motor model No. | Motor power (KW) |
Vibrating frequency (HZ) |
Double-amplitude (mm) |
Effective screening surface |
Weight (kg) |
N |
| DZSF-09x18 | ≤ 250 | 10~100 | YZO-17-4 | 0.75x2 | 25 | 5~7 | 1.62 | 1248 | 900 |
| DZSF-10x20 | ≤ 250 | 10~180 | YZO-20-6 | 1.5x2 | 16 | 6~8 | 2.0 | 1476 | 1300 |
| DZSF-12x24 | ≤ 350 | 10~200 | YZO-30-6 | 2.2x2 | 16 | 6~8 | 2.88 | 2300 | 1620 |
| DZSF-10x30 | ≤ 350 | 10~250 | YZO-30-6 | 2.2x2 | 16 | 6~8 | 3.0 | 2295 | 1850 |
| DZSF-15x30 | ≤ 350 | 10~350 | YZO-50-6 | 3.7x2 | 16 | 6~8 | 4.5 | 3300 | 2810 |
| DZSF-15x36 | ≤ 350 | 10~400 | YZO-50-6 | 3.7x2 | 16 | 6~8 | 5.4 | 4460 | 4800 |
| DZSF-15x40 | ≤ 350 | 10~450 | YZO-75-6 | 5.5x2 | 16 | 6~8 | 6.0 | 5028 | 4650 |
| DZSF-15x50 | ≤ 350 | 10~500 | YZO-75-6 | 5.5x2 | 16 | 6~10 | 7.5 | 6800 | 5100 |
| DZSF-20x50 | ≤ 350 | 10~500 | YZO-75-6 | 5.5x2 | 16 | 6~10 | 10 | 8450 | 6130 |
| DZSF-20x60 | ≤ 350 | 10~600 | YZO-100-6 | 7.5x2 | 16 | 8~12 | 12 | 11100 | 7600 |
| DZSF-20x70 | ≤ 350 | 10~600 | YZO-100-6 | 7.5x2 | 16 | 8~12 | 14 | 13800 | 10110 |
| DZSF-20x80 | ≤ 350 | 10~600 | YZO-100-6 | 7.5x2 | 16 | 8~12 | 16 | 17500 | 111040 |
Assembling
