Industrial Power Supply Switching 12v
US$ 50 - 500
/ Set
50 Sets(Min. Order)
- SHENZHEN
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | ASPOWER | |
| Model Number | U1A-C20500-D | Output Power | Other, 300W~500W | |
| Output Type | Multiple | Input Voltage | Other, 90V~264Vac |
Product Description
Product Description
| Model No | Watt |
| U1A-C20600-D | 600 |
| U1A-C20500-D | 500 |
| U1A-C20450-D | 450 |
| U1A-C20400-D | 400 |
| U1A-C20350-D | 350 |
| U1A-C20300-D | 300 |
| Input | Model No | Voltage | Frequency | Current(Unit:A) | Inrush Current | PFC | EMI | EMS | |||
| 115Vac | 230Vac | 115Vac | 230Vac | 115Vac | 230Vac | ||||||
| U1A-C20600-D | 100~240Vac | 50/60Hz | 6.5 | 3.5 | 20A | 40A | >0.98 | >0.95 | IEC-6100-3-2 FCC CISPR22(EN55022) | EN61000-4-2ESD EN61000-4-4EFT EN6100-4-5Surge | |
| U1A-C20500-D | 5 | 2.5 | 20A | 40A | >0.98 | >0.95 | |||||
| U1A-C20450-D | 5 | 2.5 | 20A | 40A | >0.98 | >0.95 | |||||
| U1A-C20400-D | 4 | 2 | 20A | 40A | |||||||
| U1A-C20350-D | 4 | 2 | 20A | 40A | |||||||
| U1A-C20300-D | 5 | 1.5 | 20A | 40A | >0.98 | >0.95 | |||||
| Output | 80PLUS | Model No | Watt | Output | ||||
| "+5V | "+3.3V | "12V1 | "-12V | 5Vsb | ||||
| 80PLUS GOLD | U1A-C20600-D | 600 | 25A | 25A | 48A | 1A | 3A | |
| U1A-C20500-D | 500 | 25A | 25A | 40A | 1A | 3A | ||
| U1A-C20450-D | 450 | 23A | 23A | 36A | 1A | 3A | ||
| U1A-C20400-D | 400 | 21A | 21A | 32A | 1A | 3A | ||
| U1A-C20350-D | 350 | 20A | 20A | 26A | 1A | 3A | ||
| U1A-C20300-D | 300 | 18A | 18A | 24A | 1A | 3A | ||
| Regulation Load | ±5% | ±5% | ±5% | ±10% | ±5% | |||
| Ripple And Noise | 50mV | 50mV | 120mV | 120mV | 50mV | |||
| Remarks:+3.3V and +5V Total output power not exceed:400~500W@150W,300~350W@120W | ||||||||
| Specifications | ||||
| Efficiency | >90% Typical Load at 115Vac | |||
| Power Good Signal | On Delay 100mS to 500mS | |||
| Hold Time | 16mS Minimum at 115V 80% Full Load | |||
| Rise Time | 20mS Maxminum at 115V Full Load | |||
| Output Protection | Short,OPP,OCP,OVP,OTP | |||
| Temperature Range | Operating 0℃~50℃, storage-20℃~80℃ | |||
| The power supply meet EN60950,EMC,EMI Class B Regulations | ||||
