1.excellent quality
2.low price
3.experience in this field for many years
Airslide-Shengquan offer a comprehensive range of Poly Airslide for use in air gravity conveyors.Air gravity conveyors are used to move dry particle material in a variety of industries such as cement,detergent,transportation(bulk haulers,barges).
Our products are semi-permeable(allow air to pass through
but not product) and manufactured to meet specific permeation range ensuring that uniform volumes of air are allowed to pass through,given standard air pressure.
Polyester Airslide is manufactured in 2-5 ply from durable and abrasion resistant polyester fabrics.Airslide fabrics and Airslide pads form an intergral part of Pneumatic Conveyor Systems.
The product is made of high quality polyester fiber. Applicable to cement the air chute, silo aeration tank pneumatic conveying and bulk cement special vehicle, special bulk cement ships, power plants, aluminum and other dust materials, pneumatic conveying, conveying powder material is the core material.
Material: Polyester staple fiber warp weft large chemical fiber filament Polyester.
Thickness:4-8mm Width:100-240mm
Temperature:
room temperature: 160 degrees
moment: 180 degrees.
Product Code : ESPEAS-B5
TECHNICAL DATA | |
Product name |
spun and filament mixed polyester air slide |
weight |
3600gsm+/- 5% |
Thickness |
5mm+/-0.3mm |
Air permeability |
90 L/m2.s+/- 10% |
|
Elongation (Strength:2000N/2cm ) Warp weft |
2.1% 1.0% |
Working temperature |
160°C |
Number of plies |
5 |
Above data are the averages obtained from a series of typical by our lab and just for reference only.
