BZC350DF Water Well Drilling Rig
US$ 1 - 123,900
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
For 400 Meters Water Well Drilling Rig FactoryUS$ 1 - 60,000MOQ: 1 Set -
For Egypt Market Truck Mounted Water Well Drilling RigUS$ 1 - 148,000MOQ: 1 Set
-
300m Mobile Water Well Drilling RigUS$ 1 - 120,000MOQ: 1 Set
-
500m Rotary Truck Mounted Water Well Drilling RigUS$ 146,000 - 200,000MOQ: 1 Set
-
400m Rotary Truck Mounted Water Well Drilling Rig Suitalbe for AfricaUS$ 110,000 - 170,000MOQ: 1 Set
Condition
New
Type
Rotary Drilling Rig
Power Type
Diesel
Place of Origin
Shandong, China
Brand Name
BINZUAN brand
Model Number
BZC350DF
Usage
Water Well
Voltage
380 V
Power(W)
90 KW
Dimension(L*W*H)
12160*2490*3740 MM
Weight
19 tons
Certification
ISO9001:2008
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Truck mounted water well drilling rig BZC350DF
1.BZC350DF truck mounted water well drilling rig is equipped with DONGFENG special 6x4 truck chassis.
And BZC350DF drilling rig's main drilling technology is mud positive cycle, but according to the geological conditons, it is also can be equipped with air compressor to achieve pneumatic DTH hammer drilling and other
Mud positive cycle drilling technology.
2.Technical parameters as follow:
Technical parameter | ||||
Drilling depth(M) |
350 |
|||
Drilling diameter(mm) |
500 |
|||
Speed of turntable(r/min) |
50;75;114(reverse) |
|||
Torque of turntable(KN.m) |
13.2;8.8;5.8(reverse) |
|||
Single rope lifting capacity of mian windlass(KN) |
30 |
|||
The capacity of main windlass(KN)
|
180 |
|||
| Single rope lifting capacity of hydraulic windlass(KN) | 30 | |||
| The capacity of hydraulic windlass(KN) | 120 | |||
| The lifting capacity of hook(KN) | 180 |
|||
Bearing capacity of mast (KN) |
180 |
|||
The height of mast (mm) |
11900 |
|||
Bearing capacity (t) |
25 |
|||
Pipe |
Kelly bar(mm) |
108×108×7500 |
||
Assistant pipe (mm) |
89×10×5500 |
|||
|
Hydraulic pump
|
Model |
CB-HP50/32Z |
||
Pump delivery (ml/r) |
50/32 |
|||
Rated speed (r/min) |
2000 |
|||
Rated pressure(MPa) |
20 |
|||
|
BW850/2A
plunger pump
|
Diameter of cylinder (mm) |
150 |
||
Stroke of piston (mm) |
180 |
|||
Theory of flow (L / min) |
600 850 |
|||
Rated pressure (Mpa) |
3 2 |
|||
Pounding times (min-1) |
58 82 |
|||
Diameter of suction tube (mm) |
127 |
|||
Diameter of drain pipe (mm) |
64 |
|||
Input speed (r / min) |
470 |
|||
Input power (kw) |
40 |
|||
Overall dimensions (mm) |
2000*1030*1400 |
|||
Weight (t) |
1.5 |
|||
|
Truck chassis
|
Model |
DFS1251GLJ8 |
||
Drive form |
6×4 |
|||
|
Engine
|
Model |
YC6J180-33(Europe IV emission standard) |
||
Rated power(KW) |
132 |
|||
Speed (r/min) |
2500 |
|||
Size (L*W*H)(mm) |
11110×2490×2500 |
|||
Drilling engine |
Model |
NC611ZG17-20 |
||
Rated power (kw) |
115 |
|||
Speed (r/min) |
1100 |
|||
The best working gear (or speed) |
5th gear(1000-1400r/min) |
|||
The highest speed(Km/h) |
75 |
|||
Weight (kg) |
19340 |
|||
Transport size(L*W*H)(mm) |
12400*2480*3700 |
|||
Working size(L*W*H)(mm) |
10900*4500*13600 |
|||
Dear friend, if you are interested in BINZUNA brand water well drilling rig, please don't be hesitate to contact us, we will supply our best service and choose the best suitable water well drilling rig according to your demands, so we are looking forwards to your reply.
Thanks & Best regards.
