BZC350DF truck mounted drilling rig export of Mozambique drought

FOB Price

USD $94,000 - $94,666 / Set

1 Set(Min.Order)

Supply Ability 12 Set / Sets per Month
Port TIANJIN SHANGHAI GUANGZHOU SHENZHEN QINGDAO

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Core Drilling Rig
Power Type	Electric	Place of Origin	Shandong, China
Brand Name	BINZHOU DRILLING MACHINE	Model Number	BZC350DF
Usage	Water Well	Voltage	380
Power(W)	115	Dimension(LWH)	1240024803700
Weight	17340kg	Certification	ISO9001
Warranty	one year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Main features:

1 BZC350DF truck mounted drilling rig is designed by our engineers; it adopts truck mounted and is a rotary drilling rig.

2 The truck chassis adopts the 6X4 special crane chassis of brand DONGFENG TRUCK, the main transmit, transmission power, gearbox, sets of windlass, mud pump, sewage pump,mast are set up on the chassis.

3This rig is a rotary drilling rig with directional circulation, which is equipped with BW850/2A mud pump, It adopts the slurry as the washing fluid, it can drill on clay, sand and rock if it is equipped with a good drilling bit.

4 The power of drilling rig comes from the NC6110ZG17-20(115kw) independent engine, the rig setups distribute implement and hydraulic system.

5 We can upset the spare electric engine and clutch implement according to client's requirement, so that the rig can work with diesel engine or electric engine.

6The adding pressure device is hydraulic, so it has a high efficiency when the rig drill on mud rock and weathering formation through using the adding pressure implement.

7 The master driving of rig is mechanical, the four jacks and mast are hydraulic operated. Distribute box, sewage pump, master driving clutch system are air operated.

8 The appearance of rig is pretty, it has a high efficiency because of having a larger torque of the turntable, it is mainly used for water well, construction, national defense building foundation, geological exploration, geothermic well and other foundation working, it is popular with domestic and foreign clients.

Technical parameter
Drilling depth(M)				350
Drilling diameter(mm)				500
Speed of turntable(r/min)			50;75;114(reverse)
Torque of turntable(KN.m)			13.2;8.8;5.8(reverse)
Single rope lifting capacity of mian windlass(KN)			30

The capacity of main windlass(KN)			180
Single rope lifting capacity of hydraulic windlass(KN)			30
The capacity of hydraulic windlass(KN)			120
The lifting capacity of hook(KN)			180
Bearing capacity of mast (KN)			180
The height of mast (mm)			11900
Bearing capacity (t)			25
Pipe	Kelly bar(mm)		108×108×7500
	Assistant pipe (mm)		89×10×5500
Hydraulic pump	Model		CB-HP50/32Z
	Pump delivery (ml/r)		50/32
	Rated speed (r/min)		2000
	Rated pressure(MPa)		20
BW850/2A plunger pump	Diameter of cylinder (mm)		150
	Stroke of piston (mm)		180
	Theory of flow (L / min)		600 850
	Rated pressure (Mpa)		3 2
	Pounding times (min^-1)		58 82
	Diameter of suction tube (mm)		127
	Diameter of drain pipe (mm)		64
	Input speed (r / min)		470
	Input power (kw)		40
	Overall dimensions (mm)		200010301400
	Weight (t)		1.5
Truck chassis	Model		DFS1251GLJ8
	Drive form		6×4
	Engine	Model	YC6J180-33(Europe IV emission standard)
		Rated power(KW)	132
		Speed (r/min)	2500
	Size (LWH)(mm)		11110×2490×2500
Drilling engine	Model		NC611ZG17-20
	Rated power (kw)		115


	Speed (r/min)		1100



The best working gear (or speed)			5^thgear(1000-1400r/min)
The highest speed(Km/h)			75
Weight (kg)			19340
Transport size(LWH)(mm)			1240024803700
Working size(LWH)(mm)			10900450013600
