Home > Products > Fanless Panel PC > 46 inch industrial touch panel pc with CE, RoHs, FCC, ISO 9001
46 inch industrial touch panel pc with CE, RoHs, FCC, ISO 9001
- 8000 Set / Sets per Month
- Hongkong or Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Products Status: | Stock | Type: | Panel PC | Brand Name: | Anrecson or OEM |
Model Number: | LC-IPC4601T-IR |
Product Description
46 inch industrial touch panel pc with CE, RoHs, FCC, ISO 9001
Feature Descriptions :
various sizes from7"--82" such as:7",8",10.4",12.1".15",17‘,18“,19”20",21.5",22",24",26",32’,37“,40”,42“,46”etc
1. CPU: Intel core P7350(optional Intel Core 2 Duo, Core 2 Solo,Celeron M CPU)
2 .DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional)
3.SSD 16G (optional), Resistive 5 W touch
4. Sumsang panel,High configuration,vibration proof
5.wide temperature and humidity
6. Open Frame touch( or industrial panel PC with aluminum bezel optional)
7. Any customized service
8.CE, RoHS, FCC, CCC certificates.
9. for medical panel PC, marine panel PC, for information display, embedded in industrial automatic device
Data sheet:
Item | Project | parameter | ||||
LCD Display | Display Type/Size | Color TFT LCD/46″ | ||||
Active Display Area (mm) | 1018.08mm(W)×572.67mm(H) | |||||
Display Mode | 16:9 | |||||
Max Resolution | 1920 X 1080 | |||||
Support Color | 16.7M | |||||
Luminance(cd/m2) | 400cd/m2 | |||||
Backlight | LED backlight | |||||
Contrast Ratio | 5000:1 | |||||
Pixel Pitch | 0.53025(H)×0.53025(V) | |||||
Response Time | 5.5ms | |||||
Viewing Angle | 178/178(H/V) | |||||
Processor System | Chip set | Intel Core2 Duo CPU+GM45+ICH8M | ||||
CPU | Intelcore P7350(optional Intel Core 2 Duo, Core 2 Solo,Celeron M CPU) | |||||
Internal memory | DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) | |||||
Hard disk | 16GB high speed solid state disk (optional) | |||||
VGA ports | 1xVGA Ports/1xHDMI Ports | |||||
COM ports | Defaultx4 COM(optional) | |||||
Ethernet ports | One Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) | |||||
Audio | with Realtek ALC662 Line-In/Line-Out/Speaker out with 3W AMP Circuit | |||||
USB ports | Defaultx4 USB(Max x6) | |||||
Touch Type | TouchScreen Type | IR Touch | ||||
TouchScreen interface | Serial (RS232) or USB | |||||
Power supply | Input Voltage | AC100V~240V,50/60Hz | ||||
Output Rating | <=140W | |||||
Temperature Range | Operating Temperature | -20~70°C | ||||
Storage Temperature | -20~70°C | |||||
Relative Humidity | 20(%RH)~90(%RH) |
Company Showing
CeBIT Hannover 2013, Canton Fair, 2013 ISC WEST, China Sourcing Fair(HK), EXPOSEC 2013(Brazil), Computex Taipei 2013
Worldwide supplier of lcd monitor(open frame monitor, industrial monitor, touch monitor, CCTV monitor, medical monitor, etc), Panel PC, high brightness product, lcd digital signage, transparent LCD, Since 1998
Contact Us
- Shenzhen Anrecson Electronics Co., Ltd.
- Contact namevivien zhang
- Phone86-0755-29966389
- AddressFloor 5,Building B3, Feng Huanggang, No.3 Industrial Zone, Xi Xiang Town, Bao'an District, Shenzhen Shenzhen,Guangdong
