24 Inch Touch Panel PC

24 Inch Touch Panel PC thumbnail-1
24 Inch Touch Panel PC photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Panel PC
Brand Name:
Anrecson or OEM
Contact Supplier Request Quote Chat Now
Shenzhen Anrecson Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Hongkong or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Panel PC
Brand Name Anrecson or OEM
Model Number LC-IPC2401T-IR

24 inch touch Panel PC



Feature Descriptions :



various sizes from7"--46" such as:7",8",10.4",12.1".15",17‘,18“,19”20",21.5",22",24",26",32’,37“,40”,42“,46”



1. CPU: Intel core P7350(optional Intel Core 2 Duo, Core 2 Solo,Celeron M CPU)

2 .DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional)

3.SSD 16G (optional), Resistive 5 W touch

4. Sumsang panel,High configuration,vibration proof

5.wide temperature and humidity

6. Open Frame touch( or industrial panel PC with aluminum bezel optional)

7. Any customized service

8.CE, RoHS, FCC, CCC certificates.

9. for medical panel PC, marine panel PC, for information display, embedded in industrial automatic device

24 inch touch Panel PC



Data sheet:



LC-IPC2401T-IR Panel PC all in one
Specifications
Item Project parameter
LCD Display Display Type/Size Color TFT LCD/24″
Active Display Area (mm) 521.28x293.22(mm)
Display Mode 16:10
Max Resolution 1920 X1080
Support Color 16.7M
Luminance(cd/m2) 300cd/m2
Backlight LED backlight
Contrast Ratio 1000:1
Response Time 1.5ms
Pixel Pitch 0.2715(H)×0.2715(V)
Viewing Angle 170/178(H/V)
Processor System Chip set Intel Core2 Duo CPU+GM45+ICH8M
CPU Intelcore P7350(optional Intel Core 2 Duo, Core 2 Solo,Celeron M CPU)
Internal memory DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional)
Hard disk 16GB high speed solid state disk (optional)
VGA ports 1xVGA Ports/1xHDMI Ports
COM ports Defaultx4 COM(optional)
Ethernet ports One Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.)
Audio with Realtek ALC662
Line-In/Line-Out/Speaker out with 3W AMP Circuit
USB ports Defaultx4 USB(Max x6)
Touch Type TouchScreen Type Resistive(4-wire/5-wire),SAW
Optional Touch Type IR, Capacitive
TouchScreen interface Serial (RS232) or USB
Power supply Input Voltage DC12V 4A
Output Rating <=65W
Temperature Range Operating Temperature -20~70°C
Storage Temperature -20~70°C
Relative Humidity 20(%RH)~90(%RH)



 24 inch touch Panel PC24 inch touch Panel PC

 Company Showing



24 inch touch Panel PC24 inch touch Panel PC





CeBIT Hannover 2013, Canton Fair, 2013 ISC WEST, China Sourcing Fair(HK), EXPOSEC 2013(Brazil), Computex Taipei 2013







Worldwide supplier of lcd monitor(open frame monitor, industrial monitor, touch monitor, CCTV monitor, medical monitor, etc), Panel PC, high brightness product, lcd digital signage, transparent LCD, Since 1998
