Industrial VTM/TVM/ATM/NEV Fanless 17 inch Panel PC
various sizes from7"--46" such as:7",8",10.4",12.1".15",17”,18“,19”,20",21.5",22",24"26"32”37”40”42”46”etc.
1.Intel core D525(optional N455/N475 CPU) (7"-15");
Intel core P7350(optional Intel Core 2 Duo, Core 2 Solo,Celeron M CPU) (17"~46")
2.16GB high speed solid state disk (optional)
3.Intel N2807/J1900 ; (7"~15")
DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) (17"~46")
4. Sumsang panel,High configuration,vibration proof
5.wide temperature and humidity
6. Open Frame touch( or industrial panel PC with aluminum bezel optional)
7. Any customized service
8.CE, RoHS, FCC, CCC certificates.
9. for medical panel PC, marine panel PC, for information display, embedded in industrial automatic device
| Item | Project | Specification | ||||
| LCD Display | Display Type/Size | Color TFT LCD/17″ | ||||
| Active Display Area (mm) | 337.92mm(W)×270.336mm(H) | |||||
| Display Mode | 4:3 | |||||
| Max Resolution | 1280×1024 | |||||
| Support Color | 16.7M | |||||
| Luminance(cd/m2) | 250 nits | |||||
| Backlight | LED backlight | |||||
| Contrast Ratio | 1000:1 | |||||
| Response Time | 5ms | |||||
| Pixel Pitch | 0.264(H)×0.264(V) | |||||
| Viewing Angle | 170/160(H/V) | |||||
| Processor System | Chip set | Intel N2807+NM10/J1900 | ||||
| CPU | N2807/J1900 | |||||
| Video | Intel GMA3650,640MHz | |||||
| Internal memory | DDR3(800/1066/1333MHz)Typ. 2G (Max 4G)(optional) | |||||
| Hard disk | 16GB high speed solid state disk(32GB optional) | |||||
| HDMI ports | 1xHDMI Port | |||||
| COM ports | Defaultx2 COM | |||||
| Ethernet ports | 2xRJ45 Realtek 8111E 1000 Mbps /(optional Wi-Fi connectivity supporting 802.11 a/b/g.) | |||||
| Audio |
Realtek HD ALC269Q Line-In/Line-Out/Speaker out with 1W AMP Circuit |
|||||
| USB ports | Defaultx4 USB(Max x6) | |||||
| Touch Type | TouchScreen Type | Resistive(5-wire) | ||||
| TouchScreen interface | USB | |||||
| Power supply | Input Voltage | DC12V 4A | ||||
| Output Rating | less than 35W | |||||
| Temperature Range | Operating Temperature | -20~60℃ | ||||
| Relative Humidity | 20(%RH)~90(%RH) | |||||
Package: Safe standard package or Wooden case package
Shipping: 1~15days.
Company Showing
Exihibition Showing
CeBIT Hannover 2013, Canton Fair, 2013 ISC WEST, China Sourcing Fair(HK), EXPOSEC 2013(Brazil), Computex Taipei 2013
Worldwide supplier of lcd monitor(open frame monitor, industrial monitor, touch monitor, CCTV monitor, medical monitor, etc), Panel PC, high brightness product, lcd digital signage, transparent LCD, Since 1998
After sale service
Anrecson product’s warranty time is one and a half year(LCD panel and high brightness product is 1 year).
²DOA: If any product has quality problem, excluding damages caused by natural disasters or by human factors, we will give you unconditional replacement within 30 days from the day you receive it. Anrecson will undertake all transportation expense for this replacement.
²RMA: Beyond the above mentioned 30 days but within the one and half years of guarantee time, if any product has quality problem, excluding damages caused by natural disasters or by human factors, we will undertake half of transportation fee, that is, the customer will pay the transportation fee for the goods back to Anrecson and Anrecson for the goods back to the customer.
²Paid Maintenance: Beyond the warranty time of one and a half years, if any product is in malfunction and needs repairing, the customer should pay reasonable fee for the repairment service according to the established price list of maintenance and undertake all the transportation fee in the process of repairment. After customer’s agreement, we will immediately provide our service for the customer.
