China TZL -200 Series of Industry Vacuum Used Turbine Oil Filter

FOB Price

US$ 18,000 - 22,000 / Set

1 Set(Min. Order)

Port Chongqing port
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Flow	150L/min
Working Pressure	subject to the demension	Place of Origin	Chongqing, China
Brand Name	ChongqingJuneng TZLturbine oil purification	Model Number	TZL-150
Usage	Other, used for processing turbine oil	Voltage	subject to the order
Power(W)	89	Dimension(LWH)	155012001500mm
Weight	subject to the demension	Certification	ISO9001
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

TZL -200 series of vacuum industry used turbine oil filter

TZL Purifier Series Solely Designed for Turbine Oil is case-hardened product of electric power industry. The machine adopts the latest techniques that integrate gravity, sedimentation, agglomeration, vacuum separation, adsorption, separation, and pressure filtration. It has super ability of demulsification, dehydration, degas, and removing impurity, so it is the ideal equipment for disposing wheel oil, low viscidity lubricant, and hydraulic pressure.

It is widely used in electric power, metallurgy, etc. for purifying turbo oil of steam turbine, water turbine, fuel machine and steam turbine group. It can demulsify, dehydrate and purify water-mixed, serious emulsified turbo oil, and low viscidity lubricant. It can be also used in other mechanical equipment.

Model	Unit	TZL-20	TZL-30	TZL-50	TZL-70	TZL-100	TZL-150	TZL-200
Rated Flow	L/min	20	30	50	70	100	150	200
Vacuum Range	Mpa	-0.07~-0.099
Temperature Range	°C	40~80
Oil pump pressure	Mpa	≤0.4
Total Power	kw	28	32	42	56	68	89	130
Acid value	mgKOH/g	≤0.1
Working Noise	db(A)	65~85
Cleanliness	NAS1638	≤NAS 6
Demulsifying value	min	≤15
Water content in oil	PPM	≤40
Mechanical impurity	%	No
inlet(outlet)diameter	mm	25	25	32	32	42	50	60
Dimension(mm)	L	1400	1400	1450	1500	1550	1550	1600
	W	920	950	900	940	1000	1200	1300
	H	1420	1500	1600	1650	1700	1500	1820

Dimension and weight will be changed with changing the technical specification.

If this equipment is not exactly you want, there are other oil purifier machine of our company:

    JNC Waste engine oil and black oil regeneration diesel oil equipment
    ZSC Engine Oil Purifier Series
    RZL Lubricating Oil Purifier
    RZL-B Series Lubricating Oil Purifier
    TZL Turbine Oil Purifier
    ZLA Two-Stage Vacuum Oil Purifier Series
    ZLC Two-Stage Multi-Function Vacuum Oil Purifier Series
    ZL series of high-efficient vacuum oil purifier
    TLA light fuel oil purifier series
    JL Portable-type Oil Purifier
    LY Plate Pressure Oil filtering Machine
