JL 50 Portable Filtering & Refueling Machine Series
- Chongqing port
- Money Gram
You May Like
-
JL PORTABLE FILTERING &REFUELLING MACHINE SERIES
-
JL -200 Portable Filtering and Refueling Machine,small Oil Purifier
-
Supply JL Portable Oil Filtration Unit/oil Purifier/oil Filter
-
Supply JL-70 Junnneg Portabl Oil Filter
-
JL Portable Oil Filter Machine Can Remove the Impurities From Waste Oil
-
Portable Oil Purifier Machine/movable Oil Purifier/oil Filtration
Product Details
| Condition | New | Flow | 100L/M | |
| Working Pressure | Normal Pressure | Place of Origin | Chongqing, China | |
| Brand Name | junneng | Model Number | JL-50 | |
| Usage | Lubricant Oil | Voltage | 220~415V | |
| Power(W) | 1.1-5KW | Dimension(L*W*H) | Pack | |
| Weight | 200KG | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
JL Portable Filtering & Refueling Machine Series
Usage:
This machine is fit for oil-using departments and corollary equipments. It can be used in the filtration of mechanical impurity, high-lift and long-distance oil pumping and injection.
Characteristics:
---This type of machine filters by three steps whose filtering elements gradually become intensive. It doesn’t need filter paper with several advantages such as: portable,easy-handling and environment protection .etc. It can not only filter the impurities in oil, but also satisfy the high-lift and long-distance oil pumping and injection.
Technical Parameters
Model | JL-30 | JL-50 | JL-70 | JL-100 | JL-150 | JL-200 | JL-250 | JL-300 | |
Flow (L/min) | 30 | 50 | 70 | 100 | 150 | 200 | 250 | 300 | |
Lift | 5m | 8m | 8m | 10m | 12m | 15m | 15m | 15m | |
Filter precision | 5µm | 5µm | 5µm | 5µm | 5µm | 5µm | 5µm | 5µm | |
Total Power (kw) | 0.55 | 0.75 | 1.1 | 2.2 | 3 | 3 | 4 | 4 | |
Power | 50HZ 380V | ||||||||
inlet (outlet) diameter | Made according to the customers’ demand | ||||||||
mm Dimension | L | 560 | 650 | 650 | 700 | 700 | 800 | 800 | 800 |
W | 450 | 500 | 500 | 550 | 550 | 580 | 580 | 580 | |
H | 450 | 500 | 500 | 550 | 550 | 580 | 580 | 580 | |
Attention: Dimension and weight will be changed with changing the technical specification.
