Home > Products > Oil Purifier > Various Sizes of LY Portable Filtering & Refueling Machine Series of Remove Impurities of Oil Recycling
Various Sizes of LY Portable Filtering & Refueling Machine Series of Remove Impurities of Oil Recycling
- Chongqing port
You May Like
-
TLA-50 Industry Light Fuel Oil Filter High- Efficient Equipment
-
Chongqing Junneng LY Series of Portable Filtering & Refueling Removing Impurities Oil Purifier
-
Provide TLA-80 Light Fuel Oil/diesel Oil Purifier,dewater Oil Filtration
-
TLA-50 Light Fuel Oil Purifier/oil Recycling Machine
-
TLA-200 Light Fuel Oil Filter/Diesel Oil Filter
-
TLA-100 Diesel Oil Purifier
Product Details
| Condition | New | Flow | 30-50L/min | |
| Working Pressure | 0~0.5 MPa | Place of Origin | Chongqing, China | |
| Brand Name | Chongqinq Junneng oil purifier manufacturing | Model Number | LY series | |
| Usage | Other, Hydraulic fluid oil | Voltage | subject to order | |
| Power(W) | 0.75~505kw | Dimension(L*W*H) | subject to order | |
| Weight | subject to demension | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Various sizes of LY Portable Filtering & Refueling Machine Series of remove impurities of oil filtration equipment
LY series plate pressure oil purifier is mainly used to separate the impurities and water from the oil. It is suitable for filtering the cooking oil, transformer oil, used lubricating oil and so on. There is filtering media, such as filtering paper or filtering cloth, installed between the plastic filter board and filter plate that will be fixed to form a single filtering room under the pressure of the packing device. The filtering paper or filtering fuse packed between the filter board and filter plate will play a role of filtering. It's characterized by simple structure, easy operation, low cost, etc
Technical Parameters
Model | LY-30 | LY-50 | LY-100 | LY-125 | LY-150 | LY-200 | LY-300 | |
Rated Flow(L/min) | 30 | 50 | 100 | 125 | 150 | 200 | 300 | |
Working pressure (MPa) | 0~0.5 | |||||||
Filter Area sq.m. | ≥0.3 | ≥0.39 | ≥1.3 | ≥1.54 | ≥1.89 | ≥2.01 | ≥3.1 | |
Plate size (mm) | 280×280 | 320×320 | ||||||
Way for compressing | Manually pressed spiral | |||||||
The number of filter box | 11 | 13 | 17 | 11 | 13 | 19 | 25 | |
The Number of plate | 12 | 14 | 18 | 12 | 14 | 20 | 26 | |
Power supply | 380V 50HZ | |||||||
Total Power (KW) | 0.75 | 1.1 | 2.2 | 2.2 | 3 | 4 | 5.5 | |
Rate (r/min) | 1440 | |||||||
Filter precision (μm) | ≤5 | ≤3 | ||||||
Filter size (mm) | 285×290 | 325×330 | ||||||
Inlet diameter (mm) | φ32 | φ32 | φ42 | φ50 | φ50 | φ60 | φ60 | |
Outlet diameter (mm) | φ25 | φ25 | φ38 | φ42 | φ42 | φ50 | φ50 | |
Dimension | L(mm) | 750 | 800 | 850 | 800 | 850 | 920 | 1000 |
W(mm) | 530 | 530 | 530 | 600 | 600 | 600 | 600 | |
H(mm) | 930 | 930 | 930 | 1100 | 1100 | 1100 | 1100 | |
Weight (kg) | 80 | 95 | 130 | 180 | 210 | 250 | 300 | |
Attention:Dimension and weight will be changed with changing the technical specification.
