KL Phosphate Ester Fire-resistant Vacuum Oil Deacidifying Purifier
- chongqing port
- T/T Credit Card
You May Like
-
China ZLC Two-stage Multi-function Transformer Oil Filter
-
ZLA Two-Stage Vacuum Insulating Oil Impurity-removation, Dehydration and Degasification System
-
KL Mobile Fire-resistant Vacuum Oil Purifier
-
ZLA Two-Stage Vacuum Tramsformer Oil Impurity-removing Machine
-
ZLA Two-Stage Vacuum Insulating Oil Degassing Filter
-
ZLA Two-Stage Vacuum Switch Oil Filter
Product Details
| Condition | New | Type | Return Filter | |
| Structure | Vacuum | Place of Origin | Chongqing, China | |
| Brand Name | Junneng | Model Number | KL Fire-resistant Vacuum Oil Purifier Series | |
| Power(W) | according to your flow rate | Weight | according to your flow rate | |
| Dimension(L*W*H) | according to your flow rate | Certification | ISO9001 CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
KL Phosphate Ester Fire-resistant
Vacuum Oil Deacidifying Purifier
It is widely applied to phosphate ester fire-resistant oil system and mechanical equipment (oil filter machine).
Features:
1)The purifier is a next-generation vacuum oil filter machine destined for phosphate ester fire-resistant oil system, utilizing dewatering and degassing technologies such as anti-precipitation, aggregation, separation, transformation, resolution, vacuum entrapment and flash evaporation, which not only speedily removes the free water in oil but also intensively removes the dissolved water and gas in oil.
2) The stage-to-stage dandified filter element made of new composite materials can remove the large amount of impurities in oil and reach the purpose of precision filtration.
3) Application of new absorptive materials can effectively absorb the jelly substance in oil, eliminate the acid content in oil, and inhibit the production of new acid in the system.
4) The purifier body is made of anti-acid, anti-dissolving and stainless steel. The filter elements and seals are made of fire-resistant oil materials..
Technical Parameters
Model | KL-10 | KL-20 | KL-30 | KL-50 | KL-70 |
Rated Flow(L/min) | 10 | 20 | 30 | 50 | 70 |
Vacuum Range | -0.05~-0.099Mpa | ||||
Temperature Range | 40~65℃ | ||||
Oil pump pressure | 0.05~0.3Mpa | ||||
Power Supply | 50HZ 380V | ||||
Total Power | 20 kw | 27.5 kw | 35 kw | 49 kw | 65 kw |
Working Noise | ≤80 db(A) | ||||
Gas content in oil | ≤0.1 % mgkoH/g | ||||
Water content in oil | ≤400ppm | ||||
Cleanliness | ≤NAS 6 | ||||
Mechanical impurity | no | ||||
Dimension(mm) | 600×480×850 | 700×480×900 | 800×480×950 | 900×500×1000 | 950×500×1000 |
Attention: Dimension and weight will be changed with changing the technical specification.
