Automotive Backlites Bend Glass Tempering Furnace

Automotive Backlites Bend Glass Tempering Furnace thumbnail-1
Automotive Backlites Bend Glass Tempering Furnace thumbnail-2
Automotive Backlites Bend Glass Tempering Furnace photo-1
Automotive Backlites Bend Glass Tempering Furnace photo-2
US$ 1 - 200000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lever
Place of Origin:
China
Model Number:
LV-TB-V Series
Contact Supplier Request Quote Chat Now
Luoyang Lever Industry Co.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
120 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Lever
Place of Origin China
Model Number LV-TB-V Series
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 months
Weight 30TONS
Dimension(L*W*H) 20mx6mx6m
Production Capacity 100 sets per year
Condition New
Voltage 380KVA
Power(W) 430KW
Machine Type Glass Tempering Furnace

1. Machine Application

LV-TB-V series Double Curvature Bent Glass Tempering Machine is a specially used to produce the bend tempered glass for automobile bicklites, also for trucks, furniture, etc. Our customer produced the rear for Calldilac, Audi, Toyota, Honda, Peugeot, etc.


2. Supply Scope:

2.1. Loading table

2.2. Heating section

2.3. Double bent Forming section with mould

2.4. Quenching section

2.5. Transmission section

2.6. Cooling section

2.7. Unloading table

2.8. Blower system

2.9. Electrical & control system

2.10. Glass mould (1 set)


3. Popular size:

Model

Max. Loading Area

Min.Glass Size

Thickness

Max.Depth

(mm)

(mm)

(mm)

(mm)

LV-TB1608V

⌒1600 x ⌒800

⌒200 x ⌒300

3.5～6

150

LV-TB1810V

⌒1800 x ⌒1000

⌒200 x ⌒300

4～6

150

LV-TB2012V

⌒2000 x ⌒1200

⌒200 x ⌒300

5～6

150

LV-TB2212V

⌒2200 x ⌒1200

⌒200 x ⌒300

5～6

300

4. Machine Main Features:

4.1. In the bending forming, for transmission of pressing mould, support mould and rollers, we use servo motors & servo controllers.

4.2. In quenching section, for transmission of mould carrier, we use servo motors & servo controllers.

4.3. Equipped with heating & insulating system in forming section, which could keep temperature of the forming section so that the glass is formed in high temperature.

4.4. Easy-making and cheap moulds

4.5. Easy & quick moulds changing-time

4.6. Smaller roller distance in heating oven which guarantee the high quality

4.7. Heating section has a helix matrix structure, which can control the temperature of each area independently. Reasonable design and unique structure of heating elements make a long serve life.

4.8. The heating oven body is full closed and the Insulating materials are of high quality material with top performance which can ensure very lower energy consumption.

4.9. Ceramic roller: World-famous brand

4.10. Ceramic roller driving adopts seamless round belts.

4.11. Fault diagnosis system for the heating elements.
