Flat Glass Tempering Machine

Flat Glass Tempering Machine thumbnail-1
Flat Glass Tempering Machine thumbnail-2
Flat Glass Tempering Machine photo-1
Flat Glass Tempering Machine photo-2
US$ 1 - 200000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lever
Place of Origin:
China
Model Number:
LV-TF Series
Contact Supplier Request Quote Chat Now
Luoyang Lever Industry Co.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
120 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Lever
Place of Origin China
Model Number LV-TF Series
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 months
Weight 20TONS
Dimension(L*W*H) 20mx6mx6m
Production Capacity 100 sets per year
Condition New
Voltage 380KVA
Power(W) 530KW
Machine Type Glass Tempering Furnace

TF-SERIES FLAT GLASS TEMPERING FURNACE

Model

Max. Loading Area

Min.Glass Size

Thickness

Capacity

(mm)

(mm)

(mm)

(Batch/Hour)

LV-TF1525

1500 x 2500

150 x 280

3～19

15～17 (5mmfor example)

LV-TF2436

2440 x 3660

150 x 280

4～19

15～17 (5mmfor example)

LV-TF2442

2440 x 4200

150 x 280

4～19

15～17 (5mmfor example)

LV-TF2450

2440 x 5000

150 x 280

4～19

15～17 (5mmfor example)

LV-TF3060

3000 x 6000

150 x 320

5～19

15～17 (5mmfor example)

LV-TF3380

3300 x 8000

150 x 320

5～19

15～17 (5mmfor example)

1. Machine Application:

For producing flat tempered glass and thermal strengthened glass, which mainly used in the fields of architecture (doors, windows), shower room, garden fence, elevator, furniture, etc.


2. Main Technical Features:

2.1. Helix matrix structure for heating oven, which can control the temperature of each area independently.

2.2. Full closed heating oven and high quality Insulating materials with top performance which can ensure a minimum power consumption and uniform oven temperature.

2.3. Fault diagnosis system for the heating elements.

2.4. Advanced & specially designed high-temperature convection fans shall be applied in convection system to eliminate electro-magnetic vibration. And there is no need the water cooling system. Also, it is very easy to make the maintenance and repairment.

2.5. For the force convection fans, If power off, there is small generator providing power to convection fan which could avoid any damage because of high temperature

2.6. PID temperature control,

2.7. Preventive function for the wrong operation

2.8. Synchronous and asynchronous running of each section

2.9. Power monitoring function

2.10. Suitable for processing clear float glass, patterned glass, reflective glass, low-e glass, etc.

2.11. Standard for processed products: GB15763.5, GB9656, EN12150-1:2000, ECER-43, ANSIZ97.1, etc.

Cooperative Partners:

Product Tags: tempered glass , tempering machine , glass tempering oven
