35KV Surge Arrester YH5W-35

Specifications

Metal Oxide Surge Arrester YH5W-35KV
1.enviroment temperature -40--+40 degree
2.sea level elevation <1000m
3.more than 48Hz



35KV Surge Arrester YH5W-35

Application: For protecting rated voltage up to 220kV power transmission & distribution system from over-voltage.

Ratings: Up to 220kV.

Standards: IEC 60099-4

Features: Reliability and excellent protection based on years of experience and expertise in surge protection. Good anti-moisture capability, resistant to pollution. GIS metal oxide surge arrester, composite metal oxide surge arrester and porcelain metal oxide surge arresters are available. Long life and lightweight. Easy installation and maintenance. Good sealing capability to ensure reliable operation. High energy absorption ability.





Technical Specification:
