Polymeric Housed Metal-Oxide 24kv Lightning Arrester Without GAPS (YH10W-24)
Negotiable
MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
HAIVO
Model Number:
YH10W-24
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polymeric Housed Metal-Oxide 66KV Surge ArresterUS$ 1 - 10MOQ: 500 Pieces -
Polymer Housed Metal Oxide Lightning Arrester Without GapsUS$ 2 - 20MOQ: 500 Pieces
-
Polymeric Housed Metal-Oxide Surge Arrester Without GAPS (YH5W-10)10KV Surge ArresterNegotiableMOQ: 500 Pieces
-
9kv Lightning ArresterUS$ 10 - 20MOQ: 100 Pieces
-
11kv Polymeric Lightning ArresterUS$ 1 - 10MOQ: 500 Pieces
Place of Origin
Zhejiang, China
Brand Name
HAIVO
Model Number
YH10W-24
Specifications
Polymeric Housed Surge Arrester1.Nominal discharge current:10KA
2.Rated voltage:24KV
2..Certificates:ISO9001:2008
Polymeric Housed Metal-Oxide Lightning Arrester without GAPS (YH10W-24)
Application: For protecting rated voltage up to 220kV power transmission & distribution system from over-voltage.
Ratings: Up to 220kV.
Standards: IEC 60099-4
Features:
Reliability and excellent protection based on years of experience and expertise in surge protection.
Good anti-moisture capability, resistant to pollution.
GIS metal oxide surge arrester, composite metal oxide surge arrester and porcelain metal oxide surge arresters are available.
Long life and lightweight.
Easy installation and maintenance.
Good sealing capability to ensure reliable operation.
High energy absorption ability.
Product range:
Surge arresters 0.22kV~220kV
Technical Specification:
| Type | MOA Rated voltage KVrms() | MCOV KV(rms) | Current impulse Residual Voltage | 2ms Rectangular current impulse withstand A(crest) | 4/10μs high current impulse withstand KA(crest) | ||
| 1/4μs Lightning current impulse KV(crest) | 8/20μs Lightning current impulse KV(crest) | 30/60μs Switching current impulse KV(crest) | |||||
| YH10W-3 | 3 | 2.55 | 11.3 | 9 | 8.9 | 250 | 100 |
| YH10W-6 | 6 | 5.1 | 22.6 | 18 | 16.8 | 250 | 100 |
| YH10W-9 | 9 | 7.65 | 33.7 | 27 | 23.8 | 250 | 100 |
| YH10W-10 | 10 | 8.4 | 36 | 30 | 23 | 250 | 100 |
| YH10W-11 | 11 | 9.4 | 40 | 33 | 30 | 250 | 100 |
| YH10W-12 | 12 | 10.2 | 42.2 | 36 | 27 | 250 | 100 |
| YH10W-15 | 15 | 12.7 | 51 | 45 | 38.5 | 250 | 100 |
| YH10W-18 | 18 | 15.3 | 61.5 | 54 | 46.2 | 250 | 100 |
| YH10W-21 | 21 | 17 | 71.8 | 63 | 54.2 | 250 | 100 |
| YH10W-24 | 24 | 19.5 | 82 | 72 | 62 | 250 | 100 |
| YH10W-27 | 27 | 22 | 92 | 81 | 69.8 | 250 | 100 |
| YH10W-30 | 30 | 24.4 | 102 | 90 | 79 | 250 | 100 |
| YH10W-33 | 33 | 27.5 | 112 | 99 | 86.7 | 250 | 100 |
| YH10W-36 | 36 | 29 | 123 | 108 | 92.4 | 250 | 100 |
