Product Description
JINCHENG CAT.5 cable to meet the basic standards of the CAT.5. It is performance over the 4196 TIA SPANSI/EIA-586-A in Appendix 5 of the Enhanced CAT.5 requirements.100 MHz and about to ensure that application requirements. JINCHENG CAT.5 cable can even be used to more than 100 MHz bandwidth cabling channel,and to maintain a good stability.
Product Features
1) Decreasing length of the cable distance marker,reduced waste.
2) Very easy to install
3) Good stability
4) Small diameter, not twist at the time of instalation
Product Features
1) Impedance: (f=1-100MHz)100±15%
2) Delay deviation (max) 45ns/100m
3) Temperature range: -40 to +70°C
Industry Standard
1) ISO/IEC 11801:2002 and Edition(category 6)
2) ANSI/TIA/EIA-568-B; ISO YD/T1019-2001
3) EN 50288-6-1, EN 50173-1 compatible with all existing hardware connectivity
4) EN71 standard of green jacket
Applications
This is the most commonly used Ethernet Cable. Can be used for voice transmission and a maximum transfer rate of 100 Support for all lower-level Cat.5 cabling system.
Technical specification
| UTP cat5e stranded 4P 24AWG cable | ||||||
| |
1-Conductor | |||||
| Type: Stranded-Bare copper | ||||||
| Diameter: 0.50±0.05mm | ||||||
| 2-Insulation | ||||||
| Type: PE solid | ||||||
| Diameter: 90±0.05mm | ||||||
| 3-RIP Cord | ||||||
| Yes | ||||||
| 4-Outer Jacket | ||||||
| Type:PVC Colour:Grey | ||||||
| Thickness: ≥0.5mm | ||||||
| External Iameter: 5.4±0.2mm | ||||||
| Cable Description | ||||||
| Paramter | Unit | Value | ||||
| Max.linear tesistance. | Ω/km | ≤93.8 | ||||
| Mutual Capacity(nom). | nF/KM | 52±6 | ||||
| Insulation Resistance(20℃) | MΩ/km | ≥5000 | ||||
| Characteristic Impedance | / | 100 ±15 | ||||
| Velocity Of Propagation | % of c | 69 | ||||
| Insulation Elongation ≥ 300% | ||||||
| Electrical Characteristics | ||||||
| Frequency(MHz) | Return Loss(dB) | Attenuation(dB/100m) | Next(dB) | Psnext(dB) | Elfext | Pselfext |
| 1 | ≥20 | ≤2.9 | ≥63.3 | ≥62.3 | ≥63.8 | ≥60.8 |
| 4 | ≥23 | ≤4.1 | ≥54.3 | ≥53.3 | ≥51.8 | ≥48.8 |
| 10 | ≥25 | ≤6.5 | ≥49.3 | ≥47.2 | ≥43.8 | ≥40.8 |
| 16 | ≥25 | ≤8.2 | ≥46.2 | ≥44.2 | ≥39.7 | ≥36.7 |
| 20 | ≥25 | ≤9.3 | ≥44.8 | ≥42 | ≥37.8 | ≥34.8 |
| 31.25 | ≥23.6 | ≤11.7 | ≥41.9 | ≥39.9 | ≥33.9 | ≥30.9 |
| 62.5 | ≥21.5 | ≤17 | ≥37.4 | ≥35.4 | ≥27.9 | ≥24.9 |
| 100 | ≥20.1 | ≤22 | ≥34.3 | ≥32.3 | ≥23.8 | ≥20.8 |
About Us
Hangzhou Jincheng Industry Co., Ltd. (former Hangzhou Jincheng Plastics Co., Ltd.)was founded in 1988, the company specializes in producing PVC, PE, PP, PPR series of pipes,pipe fittings, PVC wires and cables, digital communication standard with solid polyolefin insulation and twisted pair cables (network cables), plastic inspection chamber and the PVC cable compounds. Hangzhou Jincheng Industry Co., Ltd. was named Zhejiang Province, Zhejiang Province science and technology enterprises, Province execellent products, high-tech enterprises in Hangzhou, Hangzhou brand, is focused on AAA-class hundred and integrity Enterprise, Zhejiang industrial and commercial enterprises credit AAA level "good credit" unit.
The company is located in the western suburbs of Hangzhou, the scenic town of Jingshan Lu(Tea siant)capital, land and water and convenient air transportation, business area of 50,000 square meters, construction area of 18,000 square meters, the company has assets of 130 million yuan, with advanced production equipment and technology, strong technology, with the most advanced imported and domestic testing equipment, the annual production capacity of 680 million yuan.
The company has always insisted that "science and technology innovation, first-class products, satisfactory service, continuous upgrading of quality standards to meet customer requirements," the quality, in strict accordance YD/T1019-2001, ISO3633, GB/T8815-2008, GB / T2782-2006, CJ/T233-2006 standards organizations such as the production, since 91 years, our products are qualified by the Bureau of Technical Supervision sampling products and participate in national industry standards, quality and prestige in Zhejiang Province was named products, product sales to more than 20 domestic provinces and the Americas, Europe, Southeast Asia and Hong Kong.
Companies adhere to the customer as the center in 1998 through ISO9001 quality system certification, certification in 2008 by Theil, stable product quality tends to improve the development of state enterprises to improve customer service and management network, the company chairman Mr. Zheng Jinbang, General Manager Mr. Wang Yun warmly welcome new and old customers to create the future.
Test equipment and Production equipment
Patent certificate of wire and cables
Other types of copper wire
