Rotary Switch,2 or 3 Position Selector Switch With Long Handle XB2-BJ

Zhejiang Kenaida Pushbutton Co., Ltd.
Rotary Switch,2 or 3 Position Selector Switch With Long Handle XB2-BJ thumbnail-1
Rotary Switch,2 or 3 Position Selector Switch With Long Handle XB2-BJ photo-1
US$ 0.2 - 1 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KND waterproof rotary switch,2 or 3 position selector switch
Model Number:
waterproof rotary switch,2 or 3 position selector switch XB2-BJ
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name KND waterproof rotary switch,2 or 3 position selector switch
Model Number waterproof rotary switch,2 or 3 position selector switch XB2-BJ
Protection Level IP40,IP65
Max. Current 15A
Max. Voltage 380V

Specifications

1. waterproof rotary switch,selector switch
2. CCC,CE ,ISO9001:2008,IAF,UKAS
3. certified as Yellow Supplier by CHINT

Description

                   you can add X before the waterproof rotary switch,selector switch models.   If you want one  waterproof rotary switch, selector switch for sample ,please contact us .thank you.



waterproof rotary switch,2 or 3 position selector switch Technical Parameters
Nominal insulation voltage Ui(V)380V
Rated current lth(A)10A
Rated operational voltage ue(v) 380250240125
Rated operationalcurrent le(A) AC-152.5 3
 DC-13 0.27 0.55



waterproof rotary switch,2 or 3 p selector switch Environment Features
Match a standardCB14048 5-2008,IEC 60947-5-1
Ambient temperature-25°c- +55°c
Vibration resistance≤ 500HZ , amplitude about 1.0mm
Shock resistance ≥10g
Protection levelIP40,IP65





waterproof rotary switch,2 or 3 p selector switch Contact Features
Contact action  NO or NC
Contact resistance ≤ 50mQ
Mechanical life ≥1000000
Electrical durability AC ≥100000
Short-circuit protection RT16-10A



Elucidation Contact TypeReference
rotary switch,2 or 3 position selector switch with long handle XB2-BJ2 choice button switch with long handle
rotary switch,2 or 3 position selector switch with long handle XB2-BJ1NOB2-BJ21
1NO+1NCB2-BJ25
1NOB2-BJ41
1NO+1NCB2-BJ45
3 choice button switch with long handle
rotary switch,2 or 3 position selector switch with long handle XB2-BJ2NOB2-BJ33
2NOB2-BJ53
2NOB2-BJ73



rotary switch,2 or 3 position selector switch with long handle XB2-BJ



rotary switch,2 or 3 position selector switch with long handle XB2-BJ1 The finger of comfort press to press
position and switch to turn peration
2 The function identify
3 The auto aonnect ground
4 Defend the finger get an electric
shock a design

Plate chrome metals a head and install a base
The quakeproof bolt carry son
Hard ,credibility ,as long as
3000000time machine life span
As long as 50000 hours of the service life
of the LED indicator
rotary switch,2 or 3 position selector switch with long handle XB2-BJ
Button head -touch some base a construction
The button head hold antomatic is in open the
bore
The button head revolve certain angle,card go
into touch some base



The open type connect line to carry and have
never need to prepare loose bolt

Electricity function
Most can pack 1-6 pay to touch some mold piece

rotary switch,2 or 3 position selector switch with long handle XB2-BJ

rotary switch,2 or 3 position selector switch with long handle XB2-BJ

rotary switch,2 or 3 position selector switch with long handle XB2-BJ



  rotary switch have waterproof function

  rotary switch use the fireproof material which can protact it from burning

rotary switch screw is done by environmental protection plating,after the special technology,it is better to stand wear and tear

  rotary switch contact is done by silver alloy ,which is riveting full-automatic and the working life is more than one hundred thousand times.



 rotary switch,2 or 3 position selector switch with long handle XB2-BJrotary switch,2 or 3 position selector switch with long handle XB2-BJrotary switch,2 or 3 position selector switch with long handle XB2-BJ
