Help Center60mm Mushroom Automotive Push Button Switches Silver Contact Grade A LA167-B2-BR
Related Products
-
40mm Waterproof Red Mushroom Push on Push off Switch ,grade A ,silver Contact LA167-B2-BT,B2-BXUS$ 0.2 - 1MOQ: 10 Pieces -
Waterproof Rotary Switch,2 or 3 Position Selector Switch With Long Handle Silver Contact Grade A LA167-B2-BJNegotiableMOQ: 10 Pieces
-
Waterproof Rotary Switch,2 or 3 Position Selector Switches With Light Led Silver Contact Grade A LA167-B2-BKNegotiableMOQ: 10 Pieces
-
Flat Waterproof Electrical Push Button Switch With LED ,silver Contact Grade A LA167-B2-BWNegotiableMOQ: 10 Pieces
-
Flat Waterproof Electrical Push Button Switch With LED Auto-lock,silver Contact Grade A LA167-B2-BZNegotiableMOQ: 10 Pieces
Specifications
1. automotive push button switches2. CCC,CE ,ISO9001:2008,IAF,UKAS
3. certified as Yellow Supplier by CHINT
Description
We are a manufacturing push button switch organization.push button switch is our main product.We produce all kinds of push button switch . These are our company's automotive push button switches models in the picture , you can add X before the mushroom automotive push button switches models. If you want one mushroom automotive push button switches for sample ,please contact us .thank you.
| automotive push button switches Technical Parameters | |||||
| Nominal insulation voltage Ui(V) | 380V | ||||
| Rated current lth(A) | 10A | ||||
| Rated operational voltage ue(v) | 380 | 250 | 240 | 125 | |
| Rated operationalcurrent le(A) | AC-15 | 2.5 | 3 | ||
| DC-13 | 0.27 | 0.55 | |||
| automotive push button switches Environment Features | |
| Match a standard | CB14048 5-2008,IEC 60947-5-1 |
| Ambient temperature | -25°c- +55°c |
| Vibration resistance | ≤ 500HZ , amplitude about 1.0mm |
| Shock resistance | ≥10g |
| Protection level | IP40,IP65 |
automotive push button switches Contact Features | |
| Contact action | NO or NC |
| Contact resistance | ≤ 50mQ |
| Mechanical life | ≥1000000 |
| Electrical durability | AC ≥100000 |
| Short-circuit protection | RT16-10A |
| Elucidation | Color | Contact Type | Reference | |
|
|
black | 1NO | B2-BR21 |
| green | 1NO | B2-BR31 | ||
| red | 1NC | B2-BR42 | ||
| green | 1NC | B2-BR35 | ||
| red | 1NC | B2-BR45 | ||
Our mushroom automotive push button switches have waterproof function
Our mushroom automotive push button switches use the fireproof material which can protact it from burning
Our mushroom automotive push button switches screw is done by environmental protection plating,after the special technology,it is better to stand wear and tear
The mushroom automotive push button switches contact is done by silver alloy ,which is riveting full-automatic and the working life is more than one hundred thousand times.
PACKAGING
1 If the automotive push button switches quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you.
2 Each automotive push button switches is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.
3 Every box also is sealed by polythelene bag,protecting the automotive push button switches from water.Even though double push button switch is shipped by sea.
4 The automotive push button switches are using standard packaging.
EXPORTING
1 Our customers are all around the world and the quantity demand is large.After the payment ,the automotive push button switches samples will be sent ASAP.
2 After confirming the payment ,the automotive push button switches
samples will be sent by DHL,UPS,FEDEX and so on .
