flat push button with mark two hole control box

Specifications

ntrol button
2.Certificate:CE,ISO9000
3.Working temperature
4.Diameter size:22mm/25mm

Detailed Product Description



1. mark
2. our companyis certified as Yellow Supplier by Zhejiang CHINT Electric Co.,Ltd

Description

                 These are our company's models in the picture , you can add X before the models.   If you want one for sample ,please contact us .thank you.





Technical Parameters
Nominal insulation voltage Ui(V)	380V
Rated current lth(A)	10A
Rated operational voltage ue(v)		380	250	240	125
Rated operationalcurrent le(A)	AC-15	2.5		3
	DC-13		0.27		0.55



Environment Features
Match a standard	CB14048 5-2008,IEC 60947-5-1
Ambient temperature	-25°c- +55°c
Vibration resistance	≤ 500HZ , amplitude about 1.0mm
Shock resistance	≥10g
Protection level	IP40,IP65





Contact Features
Contact action	NO or NC
Contact resistance	≤ 50mQ
Mechanical life	≥1000000
Electrical durability	AC ≥100000
Short-circuit protection	RT16-10A



	Reference	Detail			mark
	B2-B211H29	green flush  button 1NO  red flush button 1NO			START.STOP
	B2-B213	green flush  button 1NO  red flush button 1NO			1 O
	B2-B215	green flush  button 1NO  red flush button 1NO			START.STOP
	B2-B222	white flush  button 1NO  blackflush button 1NO			↑↓









PACKAGING

1 If the quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you.

2 Each product is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.

3 Every box also is sealed by polythelene bag,protecting the goods from water.Even though it is shipped by sea.

4 The goods are using standard packaging.



EXPORTING

1 Our customers are all around the world and the quantity demand is large.After the payment ,the samples will be sent ASAP.

2 After confirming the payment ,the samples will be sent by DHL,UPS,FEDEX and so on .

3 We can help your agent which in china to deal with the exporting process.

4 The goods also can be exproting by your trading company .

5 You can contact our sale department for more details.
