Home > Electrical & Electronics > Switch > Push Button Switch > 16mm Push Button Mirco Switch 24v 220v 110v Led , Ip65 Indicator Light
16mm Push Button Mirco Switch 24v 220v 110v Led , Ip65 Indicator Light
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KND
Model Number:
E6
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
16mm 2 or 3 Position Rotary Small Key Switch E6-11Y/2 E6-11FY/2 E6-11JY/2NegotiableMOQ: 10 Pieces -
16mm Mushroom Head Mininature Push Button Switch E6-11MNegotiableMOQ: 10 Pieces
-
16mm Industrial Electronic Black Buzzer E6-Y-B E6-F-B E6-J-BNegotiableMOQ: 10 Pieces
-
16mm Mushroom Head Emergency Stop Small Push Button Switch E6-11ZS E6-22ZSNegotiableMOQ: 10 Pieces
-
16mm Square Head Mininature Push Button Switch With Light 2NO+2NC KD16-11FD KD16-22FDNegotiableMOQ: 10 Pieces
Place of Origin
Zhejiang, China
Brand Name
KND
Model Number
E6
Protection Level
Other
Max. Current
Other
Max. Voltage
Other
Specifications
1.auto-lock type push button switch with indicator2.many colors available
3.good quality
Description
Zhejiang Kenaida push button CO.,LTD is a professional push button and indicator manufacturer,Through years of painstaking operation and development , we had own more than 30 series of push button and accessories , and researched 1-2 series of new products.
These are our company's models in the picture .please remind us which type and color you want .whether you want neutral(no brand) or our brand on the goods? also remind us . if you don't remind , we will sent the goods at random .thank you .If you want one piece ,please contact us.
| Rate Value | ||||
| Rated Current lth(A) | 5A | |||
| Rated Voltage (V) | 24V | 125V(110V) | 250V(220V) | |
| Direct-Current | 1A | 0.2A | 0.1A | |
| Alternating Current | P.F=1 | 5A | 3A | |
| P.F=0.7 | 3A | 2A | ||
| LED | |||||
| Type | Bidirection LED | Neon Bulb | |||
| Rated Voltage | AC/DC 6V | AC/DC 12V | AC/DC 24V | AC110V | AC220V |
| AC/DC 110V | AC/DC220V | ||||
| Color | |
|
|||
| LED Life | 30000hours | 20000hours | |||
| |||||
| Performance Characteristics | |||
| Operational temperation | -25°c - +55°c (No frozen) | ||
| Make Airiness around the product | |||
| Operational humidity | 45- 85%RH (No frost) | ||
| Contact Resistance | ≤50MΩ | ||
| Insulation Resistance | ≥100MΩ | ||
|
between the contact and the lamp pin | 2000V,AC50HZ,1min | |
| between the homopolar terminal | 1000V,AC50HZ,1min | ||
| between different terminal | 2000V,AC50HZ,1min | ||
| Endure Dibratility | 50HZ,1.2mm | ||
| Endure Impact | ≥10g | ||
| Life | auto-return button | 1000000 | |
| auto-return button,selector button | 500000 | ||
| emergency stop button , key button | 100000 | ||
| Elucidation | Reference | Colour | Action Type | |
|
|
circle | E6-XD |
|
indicator |
| indicator Square | E6-XDF | indicator | ||
| rectangle | E6-XDJ | indicator | ||
|
|
circle | E6-11 |
|
auto-resetting |
| E6-22 | auto-resetting | |||
| normal button Square | E6-11F | auto-resetting | ||
| E6-22F | auto-resetting | |||
| rectangle | E6-11J | auto-resetting | ||
| E6-22J | auto-resetting | |||
|
|
circle | E6-11T |
|
auto-locking |
| E6-22T | auto-locking | |||
| auto-lock button Square | E6-FT | auto-locking | ||
| E6-22FT | auto-locking | |||
| rectangle | E6-11JT | auto-locking | ||
| E6-22JT | auto-locking |
