Help Center16mm 2 or 3 Position Rotary Small Key Switch E6-11Y/2 E6-11FY/2 E6-11JY/2
Related Products
-
16mm Mushroom Head Mininature Push Button Switch E6-11MNegotiableMOQ: 10 Pieces -
16mm Industrial Electronic Black Buzzer E6-Y-B E6-F-B E6-J-BNegotiableMOQ: 10 Pieces
-
16mm Mushroom Head Emergency Stop Small Push Button Switch E6-11ZS E6-22ZSNegotiableMOQ: 10 Pieces
-
16mm Square Head Mininature Push Button Switch With Light 2NO+2NC KD16-11FD KD16-22FDNegotiableMOQ: 10 Pieces
-
16mm Round Head Mininature Push Button Switch 2NO+2NC KD16-11D KD16-22DNegotiableMOQ: 10 Pieces
Specifications
1.auto-resetting type rotary switch with a key2.three shapes available
3.good quality
Description
These are our company's models in the picture .please remind us which type and color you want .whether you want neutral(no brand) or our brand on the goods? also remind us .
| Rate Value | ||||
| Rated Current lth(A) | 5A | |||
| Rated Voltage (V) | 24V | 125V(110V) | 250V(220V) | |
| Direct-Current | 1A | 0.2A | 0.1A | |
| Alternating Current | P.F=1 | 5A | 3A | |
| P.F=0.7 | 3A | 2A | ||
| Performance Characteristics | |||
| Operational temperation | -25°c - +55°c (No frozen) | ||
| Make Airiness around the product | |||
| Operational humidity | 45- 85%RH (No frost) | ||
| Contact Resistance | ≤50MΩ | ||
| Insulation Resistance | ≥100MΩ | ||
|
between the contact and the lamp pin | 2000V,AC50HZ,1min | |
| between the homopolar terminal | 1000V,AC50HZ,1min | ||
| between different terminal | 2000V,AC50HZ,1min | ||
| Endure Dibratility | 50HZ,1.2mm | ||
| Endure Impact | ≥10g | ||
| Life | auto-reset button | 1000000 | |
| auto-reset button,selector button | 500000 | ||
| emergency stop button , key button | 100000 | ||
|
|
circle two position | E6-11Y/2 |
|
|
can offer two key |
| circle two position | E6-11Y/22 | protection level IP40 | |||
| circle three position | E6-11Y/3 | ||||
| Square two positon | E6-11FY/2 |
|
can offer two key | ||
| Square two positon | E6-11FY/22 | protection level IP40 | |||
| Square three positon | E6-11FY/3 | ||||
| rectangle two position | E6-11JY/2 |
|
can offer two key | ||
| rectangle two position | E6-11JY/22 | protection level IP40 | |||
| rectangle three position | E6-11JY/3 |
PACKAGING
1 If the quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you.
2 Each product is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock.
3 Every box also is sealed by polythelene bag,protecting the goods from water.Even though it is shipped by sea.
4 The goods are using standard packaging.
EXPORTING
1 Our customers are all around the world and the quantity demand is large.After the payment ,the samples will be sent ASAP.
2 After confirming the payment ,the samples will be sent by DHL,UPS,FEDEX and so on .
3 We can help your agent which in china to deal with the exporting process.
4 The goods also can be exproting by your trading company .
5 You can contact our sale department for more details
