650P twist bunching machine

FOB Price

USD $10,000 - $30,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	Jiacheng
Model Number	JC-300P/500P/500PB/ 650P/800P		Usage	Twisting

650P twisting bunching machine
1.high speed
2,twisting wire range:0.05-1.2 mm
3,twisting section:0.035-16 sq mm

650P twist bunching machine is used to twist and bunch bare copper wire, tinned wire,enameled wire and so on.

Machine's main technical parameter:

1. machine model: JC-300P/500P/500PB/650P/800P

2. Control type: PLC+HMI+Inverter control

3. Twisting section area: 0.035-16 mm²

4. Single inlet wire range:φ0.05~1.2 mm

5. Twisting pitch: 2.0-152.32 mm

6. Twisting direction: S or Z

7. Take-up tension: tension control by magnetic clutch

8. Max.main shaft speed: 1200-3000r/min

9. Traversing type: Transverse and distance can be bearing transverse

10. Bearing lubrication: Thin oil lubrication,circulation cooling

11. Bobbin loading&unloading type: Hydraulic type

12. Max.bobbin dia.: ø800

13. Auto stop unit: While reach setting length ,any wire break,or other error auto stops

14. Brake: Magnetic brake

15. Motor power: 4-11 kw

machine's detailed:
