Copper Cable Pulling equipment With Continuous Annealer/cable Making Machine And Equipment
- 100 Set / Sets per Month
- shanghai port
- T/T PayPal
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Jiacheng High Quality Cable Making Machine And Equipment | Model Number: | 450 High Quality Cable Making Machine And Equipment |
Usage: | Drawing |
Product Description
JCJX-LHT450/13 High Speed Copper Rod Breakdown Machine
It is used for drawing wire from 8mm to 1.2-3.5mm.
Main features
1.Ironed cast.
2.Horizontal structure, dual driving motors, owning rapid die change system.
3.High precision gear transmission, high efficiency, low noise.
4.Full immersed way to lubricate and cool, which can guarantee the quality of drawing die.
5.Annealing device is inclined, which is convenient for workers to cross wire. Special design air pipe to send air to the axis of annealing wheel
Inlet wire | 8mm | |
Outlet wire | 1.2-4.0mm | |
Max speed of drawing | 23m/s | |
Drawing block size | 450mm | |
Max number of passes | 13 | |
Die dimension | 38×25 | |
Capacity of the accumulator | 7m | |
Dual-reel spooling bobbin size | PND500~PND630 | |
Main motor power | 280kW (DC) | |
Power of motor for constant speed wheel | 75kW (DC) | |
Power of motor for dual-reel take up | 30kW×2 (DC ) | |
Machine dimension | 28000×4200×5000mm | |
Coiling machine quote by optional | 900mm For option | |
Anneal unit power | 70V,5000A(DC) |
Our Jiangsu Jiacheng Machinery is one of the top 10 manufacturers of producing wire and cable machinery in China. Our products have exported to India,Iran,Pakistan,Vietnam,Malaysia,Kenya,Syria,Brazil,Egypt,Bangladeshand so on. We take part in the international wire and cable machinery exhibition every two year, we also participate the exhibition in the foreign countries.
A: Advantages
1).JIACHENG has some world famous parts suppliers. Have high price performance ratio.
2).special lubrication system for the gears and bearing.
3).second section annealing system, outside electrically neutral (no current flow to other unit)
4).body and other key components and parts are produced by our own factory , quality is reliable.
5). our company’s developing process in more than 10 years.
B: After-sell service
Our company for our machine product, since the shipment date, our company free after sale maintenance service guarantee period is:
(1) 1 year for mechanical part.
(2) 6 month for electrical part.
Main Product:
Cable making equipment
v Wire drawing machine (multiple wire)
v Rod breakdown machine
v Tin-coating machine Rigid frame stranding machine
v Annealing machine
v Copper, Aluminum, Aluminum Alloy, Brass, Wire drawing machine
v Wire and cable production line
v Bunching machine
v CCA wire machine
Payment terms and contact ways
Escrow, T/T, L/C at sight
Contact: Lily Peng
Mobile: 0086-13506220296( Wechat and whatsapp)
Skype:lili19900510
Welcome to visit Jiangsu Jiacheng Group
Driving to Shanghai, we only need one and a half hours
