Specifications
Balsa Wood Laser Cutting Machine1.high cutting speed
2.high precision
3.CO2 glass laser 80W 100W
ing area 1300X900mm
Balsa Wood Laser Cutting Machine
Laser Cutting Machine JG-13090 DT
Technical Parameter
Laser Type: CO2 glass laser tube
Laser Power: 80W
Cutting Area: 1300mm×900mm
Cutting Table: Strip panel working table
No-load Max Speed: 0-24000mm/min
Repeating Location Accuracy: ±0.1mm
Motion System: Offline stepping motion control system
Cooling System: Water cooling and protection system
Power Supply: AC220V ± 5% / 50Hz
Format support: AI, BMP, PLT, DXF, DST, etc.
Standard Collocation: Mini air compressor, 550W up & down exhaust fans
Optional Collocation:
CO2 glass laser tube (65W / 100W),
CO2 RF metal laser tube (150W),
Zinc-iron honeycomb working table,
Automatic control high pressure blower valve,
Constant temperature water-chiller,
Servo system
Working size and laser power can be customized as your requirement.
Application
Applicable Materials: Wood, Balsa, Acrylic, Plywood, MDF, Glass, Plastic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Organic Glass, ABS, Paper, Paperboard, Cardboard, Leather, Marble, Bamboo, Rubber Sheet, etc.
Applicable Industries: Advertising, Signs, Signage, Sign Letters, Advertising Letters, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Precise Ornaments, Models, Architectural Models, etc.
Product Features
Girder construction and stable working table, ensure high precision laser cutting.
Optimized process area and wide application meet the requirements for various laser processing technics.
Equipped with hopper, convenient to deal with waste materials.
The Outstanding Laser Cutting Advantages Over Traditional Cutting Tools:
perfectly clean, smooth and precise edges for difficult geometries
extremely high cutting speed
ultra-high flexibility
tool-free (no retooling!!!) and contact-free technology
easy handling of machine
feature "nesting" guarantees most efficient use of materials
highly economical
Advantages of GOLDEN LASER Series Laser Cutting Machines:
Cost efficiency by the application of low maintenance technologies and maintenance-free sealed CO2 lasers.
Engrave and cut a wide variety of materials.
Faster speed, higher precision and laser power.
High speed Galvo engraving and X-Y axis cutting integrated system.
High efficiency engraving and cutting separated system.
Unique ultrasonic auto-focus system.
Automatic CCD Camera recognizing and cutting system.
Metal and non-metal cutting all in one.
Highest quality laser motion control system.
Complete exhaust and filtering of cutting emissions possible.
Ergonomic loading and unloading system without time-consuming.
Secured and intuitive control of the systems with software-independent.
Prompt & Good After-sale Service:
1> One year guarantee for the whole set of machines, not including normal replacement of wearing parts.
2> 24 hours technical support by email or calling. When it is necessary, we will send technician to the customer side to solve the problem.
3> User-friendly English manual and CD for machine using and maintaining.
4> Free lifetime upgrading of self-developed English software.
