Specifications
JG-13090 wood laser engraving cutting machine1)65W 80W 100W
2)Dual core laser system
3)golden laser software
4)high speed
JG-13090 wood laser engraving cutting machine
JG-13090SG/JGSH-13090SG Laser Cutting and Engraving Machine
Technical Parameter:
Laser Tube: CO2 glass laser tube
Laser Power: 80W (JG-13090SG) 80W×2 (JGSH-13090SG)
Cutting Area: 1300mm×900mm
Working Table: Strip panel working table (Automatic up & down distance: 0-150mm)
No-load Max Speed: 0-24000mm/min
Repeating Location Accuracy: ±0.1mm
Motion System: Offline stepping control system
Power Supply: AC220V ± 5% / 50Hz
Format Support: AI, BMP, PLT, DXF, DST, etc.
Standard Configuration: 550W up & down exhaust fan, mini air compressor
Optional Configuration:
1. CO2 glass laser tube (65W / 100W),
2. Auto focus system,
3. Rotary engraving device,
4. Automatic control high pressure blower valves,
5. Constant temperature water-chiller,
6. Zinc-iron-alloy honeycomb working,
7. Servo system.
8. Dual core laser system
9. Double laser head
Working size and laser power can be customized as your requirement.
We also supply large format laser machine with working areas: 1300X2500mm, 1350X2000mm, etc.
Machine Highlights:
- This machine has extensive working range and large working area.
- Auto up-down working table meets the requirements for processing different area materials and also ensures the best focus and processing effect of different thickness materials.
- It can also be equipped with rotary system to do fine engraving on various non-metal cylindrical materials such as wood, bamboo, etc.
Application:
Applicable Materials: Wood, Acrylic, Plywood, MDF, Glass, Plastic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Organic Glass, ABS, Paper, Paperboard, Cardboard, Leather, Marble, Bamboo, Balsa, etc.
Applicable Industries: Advertising, Signs, Signage, Sign Letters, Advertising Letters, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Precise Ornaments, Models, Architectural Models, etc.
Advantages of GOLDEN LASER Series Laser Cutting Machines:
Cost efficiency by the application of low maintenance technologies and maintenance-free sealed CO2 lasers.
Engrave and cut a wide variety of materials.
Faster speed, higher precision and laser power.
High speed Galvo engraving and X-Y axis cutting integrated system.
High efficiency engraving and cutting separated system.
Unique ultrasonic auto-focus system.
Automatic CCD Camera recognizing and cutting system.
Metal and non-metal cutting all in one.
Highest quality laser motion control system.
Complete exhaust and filtering of cutting emissions possible.
Ergonomic loading and unloading system without time-consuming.
Secured and intuitive control of the systems with software-independent.
Samples of wood laser engraving cutting:
Please confirm us below when sending enquiry:
1. What kind of machine do you need? Laser cutting or laser engraving or laser marking?
2. What materials do you need to process? The size and thickness?
3. What is your business scope? Are you an end user or distributor?
We will be very happy to help you in any way we can.
