Fiber laser surgical instruments marking machine

Wooden Case Package

Specifications

Fiber laser surgical instruments marking machine
Q-switched
lifetime over 100,000 hours
lower utility cost
Ytterbium fiber

Fiber laser surgical instruments marking machine



Advantages of the fiber laser include…

• Fully integrated design merges the individual components of the solid-state laser into a single functional element.
• Eliminates the need for periodic optics alignment as the cavity optics are an integral part of the fiber.
• Eliminates the need for periodic inspection of the optical surfaces including the cavity mirrors, Q-switch and rod ends.
• Eliminates the possibility of damage to intracavity optics from contaminated surfaces.
• Projected diode lifetime of over 100,000 hours for the fiber laser is significantly longer than the YAG laser for an overall lower cost of operation.
• More efficient diode pumping provides lower utility cost.
• The Ytterbium fiber laser provides the user with a zero-maintenance, highly reliable laser source.



The Q-switched, Ytterbium fiber laser generates a high-intensity beam of near-infrared light at the 1.07 micron wavelength. In Q-switched operation, the laser is pulsed at a pulse rate between 20 kHz and 80 kHz to produce the high peak powers required to create highly legible marking images.

The fiber laser delivers the high power laser beam directly to the beam-steering optics via a flexible metal-sheathed single mode fiber cable. The laser beam is subsequently directed across the target surface by mirrors mounted on high-speed, high-accuracy galvanometers controlled by the system computer. The part-marking program instructs the galvanometers to move the beam just like a pencil on paper to "draw/write" the programmed marking image.



Technical Parameter

Model No.:     GDBGX-20 Fiber Laser Marking Machine

Laser generator:     Fiber Laser

Laser power:   20W

Standard marking area:   70mm×70mm

Optional marking area:   35mm×35mm, 110mm×110mm, 130mm×130mm, 175mm×175mm

Working table:       Manuel up and down aluminium alloy working table

Marking speed:      0-2000mm/s

Cooling system:      Air cooling

Control system:      Digital offline control

Galvo positioning accuracy:   ±0.01mm

Power supply:       AC220V ± 5% / 50/60Hz

Format support:     AI, BMP, PLT, DXF, DST, etc.

Optional:

Rotary device for cylinder marking

Auto focus for different thickness objects marking

10W Fiber laser

30W, 50W high pulsed power for deeper engraving



Good & Prompt Global After-sale Service:

1. One year guarantee for the whole set of machines, not including normal replacement of wearing parts.

2. 24 hours technical support by email or calls. When it is necessary, we will send technician to the customer side to solve the problem.

3. User-friendly English manual and CD for machine using and maintaining.

4. Free lifetime upgrading of self-developed English software.
