Help CenterFully Automatic Control CIP Cleaning System
Related Products
The CIP cleaning system is installed on a frame and supporter which is easy for transportation especially exporting; The operating principle of the full auto CIP cleaning system means that the tank body, pipelines, pumps and all valves and also the whole processing line are cleaned on line no need to disconnect the pipes or the equipments, all cleanings are done at the closed circuit.
Main components:
CIP cleaning liquid storage tanks(include acid tank, alkali tank, hot water tank, clear water tank);
Two not big storage single layer tanks for concentrated acid and alkali.
CIP forward and return pumps.
two diaphragm pumps for acid/alkali concentrate.
heat exchanger(plate or tubular type)
One electrical appliance box
CIP systemOne set of controlling pipe and valve component.
One set of auto-performance components and parts and the electrical appliance material.
CIP cleaning liquid storage tank: 1000L-10000L.
According to the customers requirements, we can make the double circuit, three circuit, four circuit and so on, meanwhile we can make multi circuit operating at the same time.
The Heating way: plate type, coil tube type, tubular type.
System control elements:
This system adopt the PLC program to control, with the colored touch --screen to operate and display the whole process flow and also the each controlling parameter. The temperature of the cleaning liquid can be installed. It can set the PH value , the cleaning time, cleaning sequence , and also the refluence PH value. With the system malfunction alarm device.
The operating principle of the system:
1. Auto-flow control for the cleaning solution
2. Automatically regulate the temperature of the cleaning liquid.
3. Auto-compensate for the inside tank liquid level.
4. Automatically-compensation for the acid and alkali concentration.
5. Auto transfer from one cleaning liquid to another.
6. System auto alarm-device
We are looking forward to cooperate with you.
