Features
CQM Series Compact Cylinder Guide Rod Type
1.CQM series rod guide pneumatic cylinder are very wide used in automation line, compact desigh save much more sapce.
2.Normally bore size: 12mm, 16mm, 20mm, 25mm, 32mm. 40mm, 50mm, 63mm, 80mm, 100mm.
3.Available built-in magnet for auto switch(magnet sensor)
4.With self-lub bearing, the piston rod is lubrication free. Use rubber cushion for standard type to keep the cylinder operating soomthly, safely and quietly.
5.Easier and various mounting.
Specifications
Specifications:CQM Series | |||||||
Bore size(mm) |
12 |
16 |
20 |
25 |
32 |
40 |
50 |
Action |
Double acting,single/double rod |
||||||
Fluid |
Filtered compressed air |
||||||
Proof pressure |
1.5Mpa |
||||||
Operating pressure range |
0.12~1.0Mpa |
0.1~1.0Mpa |
|||||
Ambient and fluid temperature |
-10~70ºC(No freezing) |
||||||
Port size |
M5X0.8 |
1/8 |
1/4 |
||||
Cushion |
Rubber bumper |
||||||
Ordering Code
Dimensions
Detail Show
Why choose us
1: Various style for completely series pneumatic products for you to choose
2: High quality with competitive price
3: Sample order & small quantity order is ok
4: Provide free products information.
5. Reliable quality assured and active after-sell service
Payment and Shipment
Payment: T/T, Western Union, 30% deposit and 70% balance before shipping, LC, ;
Shipment: Usually we send the goods by DHL, FedEx, UPS, TNT, or EMS or as you require;
After we shipped your goods, we will send you the tracking number by E-mail.
If you do not receive it within 7 business days after shipping, please contact us.
Note:2: We do our best to ship your order in 2 week after receive your payment,and please allow 4-7 working days for the arrival of your shipment. Thank you !
Standard Model
CDQM40-10 |
CDQMA40-65 |
CDQMB16-10 |
CDQMB20-5 |
CDQMB32-50 |
CDQMB50-20 |
CDQMA100-100 |
CDQMA50-10 |
CDQMB16-15 |
CDQMB20-50 |
CDQMB32-60 |
CDQMB50-25 |
CDQMA100-20 |
CDQMA50-30 |
CDQMB16-20 |
CDQMB25-10 |
CDQMB32-75 |
CDQMB50-30 |
CDQMA100-25 |
CDQMA50-40 |
CDQMB16-25 |
CDQMB25-15 |
CDQMB40-10 |
CDQMB50-35 |
CDQMA100-30 |
CDQMA50-45 |
CDQMB16-30 |
CDQMB25-20 |
CDQMB40-100 |
CDQMB50-40 |
CDQMA32-10 |
CDQMA50-50 |
CDQMB16-5 |
CDQMB25-25 |
CDQMB40-15 |
CDQMB50-45 |
CDQMA32-100 |
CDQMA50-75 |
CDQMB20-10 |
CDQMB25-30 |
CDQMB40-20 |
CDQMB50-50 |
CDQMA32-15 |
CDQMA63-100 |
CDQMB20-15 |
CDQMB25-35 |
CDQMB40-25 |
CDQMB50-75 |
CDQMA32-20 |
CDQMA63-30 |
CDQMB20-20 |
CDQMB25-40 |
CDQMB40-30 |
CDQMB80-10 |
CDQMA32-30 |
CDQMA63-40 |
CDQMB20-25 |
CDQMB25-45 |
CDQMB40-35 |
CDQMB80-75 |
CDQMA32-40 |
CDQMA80-30 |
CDQMB20-30 |
CDQMB25-5 |
CDQMB40-40 |
CDQMB32-35 |
CDQMA32-5 |
CDQMA80-40 |
CDQMB20-35 |
CDQMB25-50 |
CDQMB40-45 |
CDQMB32-40 |
CDQMA32-50 |
CDQMB12-10 |
CDQMB20-40 |
CDQMB32-10 |
CDQMB40-5 |
CDQMB32-45 |
CDQMA32-75 |
CDQMB12-15 |
CDQMB20-45 |
CDQMB32-100 |
CDQMB40-50 |
CDQMB32-5 |
CDQMA40-10 |
CDQMB12-20 |
CDQMA40-25 |
CDQMB32-15 |
CDQMB40-75 |
CDQMB32-30 |
CDQMA40-100 |
CDQMB12-25 |
CDQMA40-40 |
CDQMB32-20 |
CDQMB50-10 |
CDQMB12-5 |
CDQMA40-15 |
CDQMB12-30 |
CDQMA40-20 |
CDQMB32-25 |
CDQMB50-15 |
CDQMB12-5 |
