Yandian 1219 self aligning ball bearings , motorcycle engines parts
1219 self aligning ball bearings:
ODM &OEM ARE WELCOME
Introduction
Self-aligning ball bearing is round balls in two races that inner ring and outer ring whose race is spherical.Application feilds
Precision instruments, low noise motors, automobiles, motorcycles, metallurgy, mill, mining, petroleum, paper making, cement, sugar and so on.
1219 self aligning ball bearings
specification
| Material | Gcr15 Material/Chrome Steel |
| Quality | P0,P6 |
| Cage,Retainer | Steel cage,Brass cage |
| Brand | Customers'brand |
| Series | 1200series,1300series,2200series,2300series |
| Certificate | ISO9001:2008,CE |
| Service | OEM&ODM self-aligning ball bearing |
| Market | Europe,South America,North America,Middle East,Southeast Asia |
| Application | used in many areas of large steel mills, aviation,aerospace,marine,railway,metallurgy,steel, mining,electricity,machinery manufacturing,printing, electronics,textiles,food,chemical,automotive etc. |
| Self-aligning Ball Bearing | |||||
| Model | Old Model | d (mm) | D (mm) | T (mm) | Weight(KG) |
| 1200 | 1200 | 10 | 30 | 9 | 0.035 |
| 1201 | 1201 | 12 | 32 | 10 | 0.042 |
| 1202 | 1202 | 15 | 35 | 11 | 0.051 |
| 1203 | 1203 | 17 | 40 | 12 | 0.076 |
| 1203K | 111203 | 17 | 40 | 12 | 0.076 |
| 1204 | 1204 | 20 | 47 | 14 | 0.119 |
| 1204K | 111204 | 20 | 47 | 14 | 0.119 |
| 1205 | 1205 | 25 | 52 | 15 | 0.144 |
| 1205K | 111205 | 25 | 52 | 15 | 0.141 |
Self-aligning Ball Bearing product show
Self-aligning Ball Bearing application
Packaging&Shinping&Payment:
1. Industrial package+outer carton+pallets.
2. Single box+outer carton+pallets.
3. Tube package+middle box+outer carton+pallets.
4. According to your's requirement.
Our service
1.Your inquiry to our product & price will be replied within 24hours
2.Well-trained & experienced staff are to answer all your inquiries in English of course.
3.OEM & ODM projects are highly welcomed. We have strong R&D team here to help.
4.Your business relationship with us will be confidential to any third party.
5.Good after-sale service offered, please get back if you got question
What is the difference between a seal and a shield on ball bearing?
Why can't we just use all seals instead of stocking both shields and seals?
Ans: The shield is attached to the outer race and it is a clearance between the outer and inner race.
On the other hand the seal is attached to the outer with the inner race.
The main reasons of not using seals in all applications instead of shields, are:
1. Speed 2. Heat and 3. Starting Torque
The seal could cause problems in these areas due to its rubbing against the inner race and in the case of
shield, there is a clearance between outer and inner race and then there is no such kind of problem.
1
On single row deep groove type seem to be loose when shaken. Are these bearings loose internally?
Ans: No, everything is fine. The bearing must have a slight amount of movement. This is necessary for running
clearance, so it does not bind. And say, before for doing this, remember to take a second to wipe off your fingers.
Linqing Xiangyang Bearing Co., Ltd specialize in taper roller bearings,deep groove ball bearing, spherical roller bearings,cylindrical roller bearings,pillow block bearings,thrust ball bearings,thrust roller bearing etc.
In addition,we can customize according to customer's demands for various types of bearings.
Brand: X&Y WYP SRBF;as your requirements,we can do the brand as your needs.
Service:OEM,Buyer Label Offered,Design Service Offered.
Company Certifications: ISO9001:2008,BV,CE
Main Markets:
Eastern Europe,South America,Domestic Market, Brazil,Russia, North America,Turkey etc.
Main Products:
1,Ball Bearings (Deep Groove Ball Bearing, Angular Contact Ball Bearing, Thrust Ball Bearing, Self-aligning Ball Bearing);
2,Roller Bearings (Taper Roller Bearing, Cylindrical Roller Bearing, Thrust Roller Bearing, Spherical Roller Bearing);
