Help CenterReliable Electric Forklift With Good Price
Related Products
-
2.7meter Full Electric Aerial Order PickerUS$ 1 - 5,000MOQ: 1 Unit -
Clamp Forklift Truck With Optional Attachment Clamp Forklift TruckUS$ 8,000 - 14,000MOQ: 1 Unit
-
HELI Diesel Forklift With Japan Genuine Engine Best Diesel ForkliftUS$ 8,000 - 14,000MOQ: 1 Unit
-
3 Ton Diesel Forklift Japan Genuine Engine HELI Transmission New Forklift PriceUS$ 9,000 - 14,000MOQ: 1 Unit
-
Forklift For Sale In Dubai 2-10 Ton Diesel Forklift For Sale In DubaiUS$ 8,000 - 14,000MOQ: 1 Unit
China Ahui Heli Co., Ltd. The forklift brand named HELI forklift. Which is the first brand in China, now ranking 8th in the world. In 2013 years, HELI forklift factory opened a second brand named CHL forklift. Same high quality with HELI forklift, but lower price. CHL forklift also has a most fully material handing product line. We have 1 ton to 46 ton forklift. And based on HELI forklift high quality, CHL forklift also has a top quality in China. For CHL electric forklift, we have two controller options. America CURTIS Controller and Italy ZAPI Controller.
1. Factory Introduction
2. Products Show
3. Details picture
4. Product testing
5. Product Standard Configuration
| Wide view mast | Stanard fork | Fork carrige | Backrest |
| Standard seat | Overhead guard raincoat | LED combined display | Pneumatic tyres |
| Traction bar | Attached tools |
6. Forklift Optional Devices and Accessories
| Boom | Cabin | Load hook | String bar |
| Hinged fork | Back view mirror | Side shifter | Papery roll clamp |
| Alarm lamp | Solid tyre | Rear work lights | Protective fences |
| Multi function barrel clamp | Load stabilizer | Widened fork carriage | Lengthened fork |
| Load pusher | Accessory hydraulic component | Roating flat clamp | Dual - tyres protector |
| Fork sleeve | Tilt / Steering cylinder protection sleeve | Colored tyre (white / green ) | |
| User-specified color | Wide view double / triplex full free mast |
7. Forklift Specifications
| Manufacture's name | ANHU HELI CO., LTD. | ||
| Model Designation | CPD20 | ||
| Configuration Number | FJ1 | FJ2 | |
| Load Capacity | Q(kg) | 2000 | |
| Load Center | c(mm) | 500 | |
| Power Type | Battery | ||
| Tyre Type | Pneumatic | ||
| Tyres Number(Front/Rear) | 41672 | ||
| Tread(centre of tyre),front | b10(mm) | 960 | |
| Tread(centre of tyre),rear | b11(mm) | 850 | |
| Tyre size,Front | 7.00-12-12PR | ||
| Tyre size,Rear | 18×7-8-14PR | ||
| Load Distance | x(mm) | 425 | |
| Mast Tilt Angle,F/R | α/β(º) | 6/12 | |
| Height with Mast Lowered | h1 | 2000 | |
| Free Lift | h2 | 170 | |
| Standard Lift Height | h3 | 3000 | |
| Height with Mast Extended | h4 | 3995 | |
| Overhead Guard Height | h6 | 2130 | |
| Fork Size | s/e/L | 45×100×920 | |
| Fork Carriage to DIN 15173 A/B | 2A | ||
| Length to fork face | L2 | 2398 | |
| Overall Width | b1 | 1150 | |
| Outside Turning Radius | Wa | 2065 | |
| Ground Clearance at mast ,Loaded | m1 | 140 | |
| Ground Clearance at centre of wheelbase, Loaded | m2 | 155 | |
| Right Stack Aisle width(Pallet size 1000×1000mm,clearance:200mm | Ast | 3748 | |
| Right Stack Aisle width(Pallet size 1200×1200mm,clearance:200mm | Ast | 3984 | |
| Travel Speed,with/without load | km/h | 14/15 | |
| Lowering Speed | mm/s | 450 | |
| Battery Voltage/rated capacity(5h) | V/Ah | 48/600 | |
| Compartment for Battery size | mm | 525×1050×807 | |
| Drive Motor-60 Min. Rating | kw | 11.1(AC) | |
| Pump Motor-15 Min.Rating | kw | 10.5(DC) | |
| Pump Motor-15 Min.Rating | kw | 12(AC) | |
| Drive Motor Control Method | MOSFET/AC | ||
| Pump Motor Control Method | MOSFET/AC | ||
| Pump Motor Control Method | MOSFET/AC | ||
| Service Brake/Parking Brake | Hydraulic/Mechanical | ||
| Relief Pressure | Mpa | 17.5 |
|
8. Forklift Optional attachments
9. Product warranty term
- 15 months or 2000 working hours (which comes first).
- We provide the replacement parts for free within the warranty period.
10. Certificates
11. FAQ
1. Who is HELI ?
HELI is the forklift first brand in China. Racking Top 9 in the global forklift Suppliers in 2012 year. Market share 32% in domestic market
and export to more than 150 countries.
2. What is brand CHL?
CHL is a new brand created by the HELI factory on 2013. It is a new business of HELI.
3. What is the difference between HELI brand forklift and CHL brand forklift ?
| Same | Difference |
| Same Factory | Different Painting Color |
| Same Components | Different Brand Name |
| Same Assembly Line | Different Brand Name |
| Same Support Team | Better Price |
4. Who is Shintool ?
Shintool machinery is the company which been officially authorized by HELI factory to sell brand “CHL” forklift which produced by the
HELI factory.
We are sincerely looking for dealers for CHL forklifts in worldwide market,
and welcome your contact any time!
12. Our Services
At Shintool machinery, we supply ONE-STOP- SHOP solution service for warehouse equipments and Chinese brand forklift
parts
Depends on 7 years experience and profession on the Chinese export business, any customer who have the business
with us and - also any other Chinese suppliers, we can be the position of supplying ONE STOP- SHOP export service. Our nearest
export port is Shanghai, and Ningbo.
We can be the main exporter who is in charger of connecting other suppliers, organizing the shipment, LCL load, one
B/L supply and other export issue service.
13. Business Range
14. Contact Us
