Help CenterAngular Mounting Square Bite Boring Arbors
Related Products
Specifications
angular mounting square bite boring arbors1.Material:high quality alloy steel.
2.Sizes:BT40-TQC25-150 etc
angular mounting square bite boring arbors:
1.Material:high quality alloy steel.
2.Sizes and specifications as below:
| Model no.model no. | D | D1 | L | W | Type of square cutter | |
| min | max | |||||
| BT40-TQC25-150 | 25 | 38 | 20 | 150 | 8 | F8-45-32 |
| BT40-TQC30-150 | 30 | 42 | 24 | 150 | 8 | F8-45-36 |
| BT40-TQC38-150 | 38 | 52 | 30 | 150 | 10 | F10-45-48 |
| BT40-TQC42-150 | 42 | 56 | 34 | 150 | 10 | F10-45-52 |
| BT40-TQC50-150 | 50 | 65 | 40 | 150 | 13 | F13-45-62 |
| BT40-TQC62-150 | 62 | 90 | 50 | 150 | 16 | F16-45-80 |
| BT40-TQC72-150 | 72 | 110 | 60 | 150 | 19 | F19-45-92 |
| BT45-TQC25-180 | 25 | 38 | 20 | 180 | 8 | F8-45-32 |
| BT45-TQC30-180 | 30 | 42 | 24 | 180 | 8 | F8-45-36 |
| BT45-TQC38-200 | 38 | 52 | 30 | 200 | 10 | F10-45-38 |
| BT45-TQC42-200 | 42 | 56 | 34 | 200 | 10 | F10-45-52 |
| BT45-TQC50-200 | 50 | 65 | 40 | 200 | 13 | F13-45-62 |
| BT45-TQC50-230 | 50 | 65 | 40 | 230 | 13 | F13-45-62 |
| BT45-TQC62-200 | 62 | 90 | 50 | 200 | 16 | F16-45-80 |
| BT45-TQC62-270 | 62 | 90 | 50 | 270 | 16 | F16-45-80 |
| BT45-TQC72-100 | 72 | 110 | 60 | 200 | 19 | F19-45-92 |
| BT45-TQC72-250 | 72 | 110 | 60 | 250 | 19 | F19-45-92 |
| BT45-TQC72-270 | 72 | 110 | 60 | 270 | 19 | F19-45-92 |
| BT45-TQC90-200 | 90 | 125 | 75 | 200 | 19 | F19-45-118 |
| BT45-TQC90-250 | 90 | 125 | 75 | 250 | 19 | F19-45-118 |
| BT50-TQC25-150 | 25 | 38 | 20 | 150 | 8 | F8-45-32 |
| BT50-TQC30-170 | 30 | 42 | 24 | 170 | 8 | F8-45-36 |
| BT50-TQC38-170 | 38 | 52 | 30 | 170 | 10 | F10-45-48 |
| BT50-TQC42-180 | 42 | 56 | 34 | 180 | 10 | F10-45-48 |
| BT50-TQC50-200 | 50 | 65 | 40 | 200 | 13 | F13-45-62 |
| BT50-TQC62-250 | 62 | 90 | 50 | 250 | 16 | F16-45-80 |
| BT50-TQC72-250 | 72 | 110 | 60 | 250 | 19 | F19-45-92 |
| BT50-TQC90-250 | 90 | 125 | 75 | 250 | 19 | F19-45-118 |
packaging way:Inner packing is by plastic box.The outer packing is by cartons.Pallet is available upon the customer's request.
Quality: Each product are inspected durding the production.And then rendomly are selceted for inspection by quality-person.We have exported our goods to around the world and get good feebacks.
Shipment way: We can send the goods by sea,air or couirer(DHL,TNT,Fedex etc) according to the customer's requirement.
Our Services and reputation: we have been the supplier at Alibaba for 8(eight) years.
We always keep our promise and are responsible for the problems if occured after sales.Pls be assured.
