BVVB BVVB+E 2 Core Awm Flat Cable for Buildings

FOB Price

US$ 0.1 - 0.45 / Meter

5000 Meters(Min. Order)

Port Shenzhen
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	YONGKUNTAI TIANXIANG or OEM
Model Number	BVVB	Insulation Material	PVC
Type	Low Voltage	Application	Overhead
Conductor Material	Copper	Jacket	PVC

Product Description

BVVB BVVB+E 2 core awm flat cable for buildings

1.ITEM DESCRIPTION:

Name: BVVB BVVB+E 2 core awm flat cable for buildings

Sheathed cable is one of the most common household wiring, usually consisted of three core( Twin & Earth ) or two-core. A high quality, well constructed product which is easily stripped and worked with. With its outer layer jacket eliminating the need for trunking and wear tube, it is very convenient used in building and construction.Building wire is fit for AC rated voltage 300/500V and below of domestic electrical appliances of smaller size motorized tools of instruments of various meters and motorized lighting installations.

Model:BVVB(without earth core),BVVB+E( Twin & Earth )

Construction:

BVVB

conductor:single solid copper wire or multi-core stranded copper wire

Insulation&sheath:PVC

BVVB+E

Specification:

number of cores*section-area of each core(sq mm)

BVVB

2×0.50, 2×0.75,2×1,2×1.5,2×2.5,2×4,2×6.

Application: General purpose flexible PVC cable suitable for use in dry domestic, commercial, indoor and outdoor conditions. It can be used for general electrical and security applications such as lawnmowers, Power Tools, Table & Floor Lamps, Radios, office equipment, lighting pendants, CCTV, Intruder Alarm and Access Control where an earth is not required.

Service Conditions

Working temperature:Not more than 70oC.

Technical data

PVC insulated PVC sheathed flat wire

Type	Name	Properties
BVVB	Copper-core PVC insulated PVC sheathed flat wire	In normal case, max. temperature of conductor shall be 70℃
BLVVB	Aluminum-core PVC insulated PVC sheathed flat wire	In normal case, max. temperature of conductor shall be 70℃

Technical data (BVVB/BLVVB)

Core number & sectional area,

Conductor

structure,

Nr./mm

Stipulated

insulation

thickness,

Stipulated

sheath

thickness, mm

Average external size, mm

20°C , DC, resistance ≤Ω/km

Min.

Max.

Copper-core

Aluminum-core

2×0.75

2×1.0

2×1.5

2×2.5

2×4

2×6

2×10

3×0.75

3×1.0

3×1.5

3×2.5

3×4

3×6

3×10

1/0.97

1/1.13

1/1.38

1/1.78

1/2.25

7/0.85

1/2.78

7/1.04

7/1.35

1/0.97

1/1.13

1/1.38

1/1.78

1/2.25

7/0.85

1/2.78

7/1.04

7/1.35

0.6

0.7

0.8

1.0

0.6

0.7

0.8

1.0

0.9

1.0

1.1

1.2

0.9

1.0

1.1

1.2

3.8×5.9

3.9×6.1

4.4×7.0

5.1×8.4

5.6×9.2

5.7×9.5

6.2×10.4

6.4×10.8

7.9×13.4

3.8×7.9

3.9×8.4

4.4×9.6

5.1×11.6

5.8×13.1

5.9×13.5

6.2×14.5

6.4×15.1

7.9×19.0

4.6×7.1

4.8×7.4

5.3×8.5

6.2×10.1

6.7×11.1

6.9×11.5

7.5×12.5

7.8×13.0

9.5×16.2

4.6×9.6

4.8×10.1

5.3×11.7

6.2×14.0

7.0×15.8

7.1×16.3

7.5×17.5

7.8×18.2

9.5×23.0

24.5

18.1

12.1

7.41

4.61

3.08

1.83

24.5

18.1

12.1

7.41

4.61

3.08

1.83

12.1

7.41

4.61

3.08

12.1

7.41

4.61

3.08

Pictures Of different Specifications

2.Our factory:

company profile:

Shenzhen Jixing Electric Wire&Cable Co.,Ltd., is a medium-sized enterprise specializing in the production of electric wire and cable.The factory covers an area of 12,000 square meters and has 500 staff,including 59 engineers and technical experts,46 inspectors.The technical operation of front-line workers come up to the average of national requirements.Through 34 years' unremitting endeavors,our company owns advanced production equipment,consummation management system,rich production experience and outstanding talented.With unflagging pursuit of excellent quality and service,Jixing enjoys a high reputation among customers in China and Overseas.

3.Our equipment:

4.Our electric cable and wire:

0.6/1KV PVC,XLPE insulated armored power cable

Environment-friendly LSZH(low smoke halogen free) cable

Flame retardant cable

Branching wire

aluminum cable

Welding cable

Internet Lan cable

control cable

THHN,THW etc UL America standard cable

CCA cable

We can also providing customizing service according to your requirement,your specificantions and sample.

5.Our Certifications:

6.Our customers:

7.Construction Case

Shenzhen Longgang Grand Canal Center Stadium

8.Our Package

9.Contract with me:

Austin

Skype:Austin Electric Cable

Wechat/whatsapp:18879133952

QQ:1795002689

Tel:13528477143
