Welcome to Shenzhen Jixing Electric Cable & Wire Co., Ltd
SHENZHEN JIXING ELECTRIC WIRE & CABLE CO., LTD (formerly: Shenzhen Jixing electric wire factory) was established in 2001, is one of the largest and specializing in research and development, manufacturing and sales of wire and cable factory in South China. The company is located in Baoan District.
Our factory:
Raw material:
Testing equipment:
Main products:
All models:
BV,BLV,BVR,BVV,BLVV,BVVB,BLVVB,RV,RVB,RVS,RVV
|
Code Designation by IEC |
Code Designation by GB |
Rated Voltage |
Name |
Application |
Rated Temperature |
60227 IEC 01 |
BV |
300/500V |
Copper conductor PVC insulated rigid cable (electrical wire) |
Fixed laid indoors Instrument etc. |
0°C to +70°C |
60227 IEC 05 |
BV |
450/750V |
|||
|
BLV |
450/750V |
Aluminum conductor PVC insulated rigid cable (electrical wire) |
||
|
BVR |
450/750V |
Copper conductor PVC insulated semi-flexible cable (electrical wire) |
Be for laying permanent place where flexible required. |
0°C to +70°C |
60227 IEC10 |
BVV |
300/500V |
Copper conductor PVC insulated PVC sheathed round rigid cable (electrical wire) |
Fixed laid, fit for the places with high mechanical protection and moisture place, can be laid in the air or underground. |
0°C to +70°C |
|
|
BLVV |
300/500V
|
Aluminum conductor PVC insulated PVC sheathed round cable (electrical wire) |
||
|
BVVB |
300/500V
|
Copper conductor PVC insulated PVC sheathed flat cable (electrical wire) |
||
|
BLVVB |
300/500V
|
Aluminum conductor PVC insulated PVC sheathed flat cable (electrical wire) |
||
60227 IEC 02 |
RV |
450/750V
|
Copper conductor PVC insulated flexible connector cable (electrical wire) |
Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required |
0°C to +70°C |
60227 IEC 06 |
RV |
300/500V |
|||
60227 IEC 42 |
RVB |
300/300V |
Copper conductor PVC insulated flat flexible connector cable (electrical wire) |
||
|
RVS |
300/300V
|
Copper conductor PVC insulated flexible twisting connector cable (electrical wire) |
||
|
60227 IEC 52
|
RVV |
300/300V
|
Copper conductor PVC insulated PVC sheathed round flexible connector cable (electrical wire) |
||
60227 IEC 53 |
RVV |
300/500V |
GBT19002(ISO9001-2000) & CCC certificate
100% quality guarantee Fast delivery Perfect after-sale service
High thermolysis effeciency
High quality with anti-dust, anti-aging
High resistance against oil, steam, bacteria
Creative technique for conductivity
High resistance against heat, clod, abrasion, UV, ozone
and hydrolysis
Flexible, easy to strip
Halongen free, high flame retardant
Instruction
It applies to electrical Appliances,instrument and telecom device with rated voltage up to and
including U/U450/750V.Long time working temperature:≤ 70
The most common used electric wires. single core, solid or stranded conductor, is equivalent to
the international model 227 IEC 01.
When using it, please check the wire insulation from the appearance in case of causing any
damage because of tansiporting or storeing not well, and influence its effect.
The cable’s allowable temperature for long time working doesn’t exceed 70°C.
The surface of the cable should not set closed to the heat producer.
Laying the cable under greenhouse less than 0C with the bend radiusnot less than 6 times of
the cable external diameter to prevent cracking.
THE CERTIFICATES:
*Kindly note that also we can make cables according to your requirements.
Your inquiry will be replied within 24 hours !
