China high quality pvc insulated earthing copper cable

Specifications

1)Quick cargo delivery
2)For home appliances
3)Low price good quality
4)PVC insulation and jacket

Specification

1)Rated Voltage: 300/500V

2)Rated temperature:0°C to 70 °C

3)Standard: GB, IEC. etc.

4)Testing Voltage: 2.5KV

5)Min. insulation resistance at 70 °C(Mohm.km): 0.0046

6)Conductor:pure copper.(more choices:copper coated aluminum,% copper+%aluminium)

7)Insolation:PVC (polyvinyl chloride) Color:green,yellow,red,brown,coffee,blue,yellow/green,black,grey

8)Sheath:PVC (polyvinyl chloride)  Color:black(white,orange,grey available)

9)Certification: CCC,CE,RoHS

10)20 years manufacturing experience

11)Specialized in electric/electrical appliances,lighting,construction,home applicances

12)Customer wire cable

13)Stock available, free sample

14)Small profits, quick returns

15)High quality and competitive price

16)Convenient transportation (One hour drive to Shenzhen port) )and timely delivery

 More Products:R Series

Model	Rated Voltage	Name	Application	Rated Temperature
60227IEC02 RV	450/750V	Copper conductor PVC insulated flexible battery cable (electrical wire)	Mainly used at middle and light style moving electronics, instrument,home appliances,industrial machine,power and lighting and the places where flexible required	0°C to +70°C
60227IEC06 RV	300/500V
60227IEC42 RVB	300/300V	Copper conductor PVC insulated flat flexible connector cable (electrical wire)
RVS	300/300V	Copper conductor PVC insulated flexible twisting connector cable (electrical wire)
60227IEC52 RVV	300/300V	Copper conductor PVC insulated PVC sheathed round flexible connector cable (electrical wire)
60227IEC53 RVV	300/500V

Packing

Option1-inside plastic film,outside several rolls in one carton
Option2-inside plastic film,outside PP bag

Option3-plywood reel



 We have the following sizes in stock,small quantity is welcome.

Model and Specification	Usage
RVV  2×0.5mm²	For  lighting as well as light duty appliances
RVV  2×0.75mm²
RVV  2×1mm²
RVV  2×1.5mm²
RVV  2×2.5mm²
RVV  2×4mm²	1.For power transfer from electrical pole to house mains 2.To connect heavy electrical appliances like stoves, conditionerand heave machinery.
RVV  2×6mm²
RVV  2×10mm²

*Kindly note that also we can make cables and wires according to your required specification.
