Azimuth Thruster

Specifications

Our hydraulic bow thruster is with enough hydraulic power to keep the thrust and speed. It's also quiet, reliable, efficient.



hydraulic bow thruster/azimuth thruster has a completed hydraulic system, which includes the motor, pump station, control device, etc.



Specifications for the hydraulic bow thruster/azimuth thruster:



Type	Propeller Dia.	Max. Thrust		Max.Input Power	Input Speed (rpm)		Propeller Speed (rpm)		Propeller Type
	mm	kN	ton	kW	60Hz	50Hz	60Hz	50Hz
TUF15	700	15.8	1.61	105	1750	1450	778	785	FP
TUF35	880	34.3	3.5	241	1750	1450	656	666	FP
TUF55	1100	53.9	5.5	378	1750	1450	532	534	FP
TUF 70	1250	68.6	7	465	1750	1450	480	483	FP, CP
TUF 90	1400	88.3	9	603	1750	1450	429	441	FP, CP
TUF 110	1550	108	11	745	1750	1450	396	393	FP, CP
TUF 135	1700	132	13.5	921	1170	1450	356	356	FP, CP
TUF 160	1850	157	16	1103	1170	1450	331	328	FP, CP
TUF 195	2050	191	19.5	1327	1170	980	299	298	FP, CP
TUF 235	2250	230	23.5	1597	1170	980	274	273	FP, CP



Tunnel Thruster, Hydraulic Thruster, Marine Thruster, Bow Thruster, azimuth thruster



Hydraulic system for the azimuth thruster :

Motor for the azimuth thruster :
