Marine High Pressure Watertight Door
- T/T
You May Like
Product Description
Specifications
Marine High Pressure Watertight Door1. High quality
2. Reasonable price
High Pressure Watertight Door
Size:
Nominal Size | Cutout in Steel Wall | External Size |
B×L×R100 | B1×L1×R150 | B2×L2×R260 |
700×1500 | 800×1600 | 1020×1820 |
700×1400 | 800×1500 | 1020×1720 |
600×1500 | 700×1600 | 920×1820 |
600×1400 | 700×1500 | 920×1720 |
Customized Size available.
Quick Details:
Dimension (mm) : 1400 * 600 * 6/8
Weight (kg) : 30.1 - 96.3
Parameters:
Length: 1400 mm
Width: 600 mm
Thickness: 6/8 mm
N.W.: 30.1 - 96.3
Material: aluminum, steel, stainless steel
Classification: LR/GL/DNV/CCS/BV/ABS/NK/KR/RINA
Packing Details:
Plywood pallet with plastic film wrapping. Max. 6 sets per packing.
Optional Model:
Available in marine steel, stainless steel and aluminum, copper materials
Hinged type, Water tight/ Weather tight and fireproof marine door
Round or Right Angle corners for option
Quick action wheel operating, Left open/ right open or sliding mechanisms
Rubber gasket three years warranty
Available in view port, door closer
Epoxy zinc rich primer coating (2 layers at least)
Customize available
OEM service and Special requirement is available
