Specifications
5.5 kw 7.5 hp Air Compressor Scroll Type1.Energy Efficient System
2.Longer usage life high performance
3.Oil lubricated
Technical Data:
8 bar 5.5 kw 7.5 hp Air Compressor Scroll Type Economic Kind China
Exhaust Volume: 0.8 M3/min , 28.25 CFM
Enviroment Temperature ( °C ): -5 to 45
Exhaust Pressure(bar/psi): 8 /116
Discharge Temperature( °C ): < Enviroment Temperature +50
Drive Method: Direct drive
Air outlet oil content : ≤ 3
Motor (KW/HP): 5.5/7.5
RPM (r/min): 2900
Power supply : 380V /50Hz
Main motor protection grade : IP 55
Noise( dB (A) ): 55 ± 3
Net Weight (kg): 140
Air Outlet Pipe Diameter ( Inch ): G3/4"
Dimension (Lx Wx H mm): 900*450*800
Contract Manufacturing:
OEM Service Offered
Other electricity supply can customize,such as 110V/1Phase/60hz,220V/3Phase/60Hz,415V/3Phase/50Hz etc.
Different size tank can also make to order .
Guarantee and after-sales service:
One year guarantee for the whole machine except maintenance parts
24 hours technical support by mail or call
Specific Features:
1. High-efficiency motor
IP55 motor (Class F insulation B rise) protects against dust and chemicals. Long-term stable operation even in harsh environments up to 46°C (115°F).
2. Efficient air-oil separation
Reduction of pressure drops and energy costs. Low oil consumption ensures minimal maintenance costs and long
compressor lifetime.
3. Superior air filtration
Two-stage dust removal and filtering system with efficiency of up to 99.9% even in heavy-duty environments (particles ≥ 3 micron). Protects compressor parts and components, ensures air quality and extends the service life of the overall air system.
4. Heavy-duty oil filter
Outstanding oil purification capability ensures a clean compressor oil system. High reliability of screws, bearings and gears
in harsh environments. Long service period and easy and quick filter change reduce maintenance costs.
Technical data chart :
