Fiber cement flat board punching machine
Application: used for High Density Fiberboard, Cement board,Gypsum board,plaster board or other ceiling board perforated.
Model: JDY25-200A
1.Length of stroke:30mm
2.Max mold height:260mm
3.Times of stroke:40-75 times/min
4.Dimensions of worktabld: 300X1640mm
5.Distance of both pole:1300mm
6.Main motor power:22KW
7.Gross weight of the machine:17500KG
8.Feeding system,computer central control.
9.Two boards to load the materials,in front and back.
Good effection for perforating: the holes are Smooth, clean, burr, and vertical.
We are sincerely invite you to our factory, and we can take you to go and see those nearby to use our equipment manufacturers.
| Technical Parameter | Model | JDY25-60 | JDY25-100 | JDY25-200A | |
| Name | |||||
| Nominal capacity | KN | 600 | 1000 | 2000 | |
| Length of stroke | mm | 30 | 30 | 30 | |
| Strokes | Fixed | min-1 | 80 | 60 | 75 |
| Variable | 50-80 | 40-70 | 40-75 | ||
| Max mold height | mm | 220 | 210 | 260 | |
| Length of stroke | mm | 50 | 50 | 100 | |
| Depht of throat | mm | - | 210 | - | |
| Bolster area (F x L) |
mm | 300x1000 | 400x1640 | 300x1640 | |
| Thickness of Bolster | mm | 160 | 150 | 150 | |
| Slide Surface (F x L) |
mm | 190x700 | 200x1300 | 300x1100 | |
| Distance of both pole | mm | 800 | 1500 | 1300 | |
| Motor | Model | KW | |||
| Power | 7.5 | 11 | 22KW | ||
| Height of table | mm | 900 | 900 | 900 | |
| Overall dimensions(LxWxH) | mm | 1400x1500 x2000 |
2400x1550 x2400 |
2510x1860 x3200 |
|
| Winght | kg | 6000 | 11000 | 17500 | |
FOSHAN JINGDUAN MACHINERY MANUFACTURE CO.,LTD is the first and only one manufacture of Gypsum board,Cement board perforating machine in China.
Common punching press
Perforating machine for Gypsum board, Fiber cement board, Calcium silicate board and other building materials
Full automatic metal perforating production line
Some project cases
Perfoating effection
