Specifications
GYTS outdoor fiber optic cable1.Sheath cable UL OFNR, OFNP requirements
2.Meet YD/T 1258.4-2005
3.2-288 core
4.CE and R
GYTS outdoor fiber optic cable for network solution
Description
The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.
Characteristics
1.Good mechanical and temperature performance
2· High strength loose tube that is hydrolysis resistant
3· Special tube filling compound ensure a critical protection of fiber
4· Crush resistance and flexibility
5· PSP enhancing moisture-proof
6· Two parallel steel wires ensure tensile strength
7· Small diameter, light weight and friendly installation
8· Long delivery length
9.2-288 core
Standards
GYXTW cable complies with Standard YD/T 769-2003.
Optical Characteristics
| ||||||||||||||||||||||||||||||||||||||||||||||||||
|
Technical Parameters | ||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||||||||
|
Storage/Operating Temperature : -40°C to + 70°C | ||||||||||||||||||||||||||||||||||||||||||||||||||
