YANYUGONGKONG - Intel desktop Firewall Industrial appliance /appliance firewall
YANYUGONGKONG offers various standard firewall Industrial appliance,They feature with reliable, high stability, industrial grade design, rich I/O. YANYUGONGKONG also provide the service of custom design to meet your special requirement
Atom D525 Desktop Firewall Networking Server with 4 Gigabit Ethernet ports / appliance firewall
| Model | R435_M5V |
| Mainboard | ITX-M5V |
| CPU | Onboard Intel® Atom dual core D525 1.8Ghz |
| Chipset | Intel® ICH8M Chipset |
| Memory | 1* SO DDR3 Solt Support 800/1066MHz,Max.2GB |
| Display | 1* DB15 VGA |
| Ethernet | 4* Intel 82583V 10/100/1000Mbps Ethernet,Support Wake-on-LAN,PXE |
| Expansion | 1* MSATA, Support SSD / USB WIFI |
| 1* Mini PCIE(support 3G/ WIFI module ) | |
| Storage | 1*MSATA ,supports mSATA SSD |
| Panel Port | 1* VGA port (COM port selectable); 1* COM(CISCO Standard) |
| 1* POWER | |
| 1* LED (POWER LED / HDD LED) | |
| 2* USB 2.0 | |
| 2*Wifi Hole (detail wifi number differ from mainboard) | |
| 4* RJ-45 | |
| FAN | 1* CPUFAN & 2* SYSFAN(3pin) |
| WatchDog | 256 level,0~255min |
| Anti-vibration | 5~300Hz/random operating |
| Power | 110~240VAC , adapter 12V 3A |
| Operate.Tem | -10°C~60°C |
| Storage.Tem | -20°C~70°C |
| Operate.Hum | 5%-95% |
| Humidity | 5%-95% (relative humidity; non-condensing) |
| Material and Process | Surface sandblasting oxidation process (Silver gray) |
| Size | 197mm(W)* 174mm(D)* 35mm(H) |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| ZM3023-M5V | ITX-M5V | D525/1.8G | DDR3 | 4*82583V | ZM3023 | 12V7A Power |
| 1U250C-M5V | ITX-M5V | D525/1.8G | DDR3 | 4*82583V | ZM3023 | 12V7A Power |
| 1UD52-SL | D52SL | D525/1.8G | DDR3 | 6*82583V | 1U250C | 12V7A Power |
| ZM3023-M5F | ITX-M5F | D525/1.8G | DDR3 | 4*8111E | ZM3023 | 12V7A Power |
| 1U250C-M5F | ITX-M5F | D525/1.8G | DDR3 | 4*8111E | 1U250C | 12V7A Power |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| 1U280SF-NM70SL_O | NM70SL_O | 1037U/1.8G | DDR3 | 4*82574L+2*82580 | 1U280SF | 12V7A Power |
| 1U280D-N70SL_B | N70SL_B | 1037U/1.8G | DDR3 | 6*82574L | 1U280D | 12V7A Power |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| ZM3023-M2F | ITX-M2F | D2550/1.86G | DDR3 | 4*82583V | ZM3023 | 12V7A Power |
| 1U250C-M2F | ITX-M2F | D2550/1.86G | DDR3 | 4*82583V | 1U250C | 12V7A Power |
| 1U280D-D25SL | D25SL | D2550/1.86G | DDR3 | 6*82583V | 1U280D | 12V7A Power |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| 1U280A-B75SL | B75SL | 1155 | DDR3 | 6*82574L | 1U280A | 1U Power |
| 1U280A-H67SL | H67SL | 1155 | DDR3 | 6*82583V | 1U280A | 1U Power |
| 1U380SF-B75SL_O | B75SL/OPT580 | 1155 | DDR3 | 6*82574L+2*82580 | 1U380SF | 1U Power |
| 1U380SF-H67SL_O | H67SL/OPT580 | 1155 | DDR3 | 6*82583V+2*82580 | 1U380SF | 1U Power |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| HTPC33-S30 | M19_30 | 1037U/1.8G | DDR3 | 1*8111E | HTPC | DC12VAdapter |
| HTPC33-S11 | M19-NC | 1037U/1.8G | DDR3 | 1*8111E | HTPC | DC12VAdapter |
| HTPC33-SI3 | M11-I3 | 3217U/1.8G | DDR3 | 1*8111E | HTPC | DC12VAdapter |
| HTPC33-SI5 | M11-I5 | 3317U/1.7G | DDR3 | 1*8111E | HTPC | DC12VAdapter |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| NFN26 | EPIC-N26 | N2600/1.6G | DDR3 | 1*8111E | N26Chassis | DC12VAdapter |
| NFN28 | EPIC-N28 | N2800/1.86G | DDR3 | 1*8111E | N28Chassis | DC12VAdapter |
| NFN28L | EPIC-N28 | N2800/1.86G | DDR3 | 1*8111E | N28LChassis | DC12VAdapter |
| Item No. | Mainboard | CPU | Memory | LAN | Chassis | Power |
| NFN80L_2G | N80L_2G | 1037U/1.8G | Onboard 2G | 2*82583V | N80LChassis | DC12VAdapter |
| NFN80L_4G | N80L_4G | 1037U/1.8G | Onboard 4G | 2*82583V | N80LChassis | DC12VAdapter |
| NFN80L_I3 | N80L_I3 | 3217U/1.8G | Onboard 4G | 2*82583V | N80LChassis | DC12VAdapter |
|
|
